Collimated lights
35 mm dia. Collimated Spot Light (LS-TP-35)
Model LS-TP-35
- ColourRed, Green, Blue, White
- Emitting areaø35
- Size44X108
- Voltage5 V
- Power4.5 W
$349.00
In stock - ships the same business day (4 available, order by 2 PM ET)
0.4 kg shipping weight
Volume pricing, Net 30 or a formal quote?
35 mm dia. Collimated Spot Light. Collimated light in which high-power LED chips produce parallel light through a condensing lens, suitable for applications needing parallelism or medium-to-long distance illumination. Used for high-precision dimension inspection, deep-hole measurement and surface defect detection.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-TP-35 |
|---|
Light
| Emitting area (mm) | ø35 |
|---|---|
| Colours | Red, Green, Blue, White |
| LED colour options (legend) | R / G / B / W |
| Colours shown per model | R, G, B, W |
Electrical
| Voltage (V) | 5 |
|---|---|
| Power R (W) | 3 |
| Power W/B/G (W) | 4.5 |
Mechanical
| Outer size ODxH (mm) | 44X108 |
|---|---|
| Shipping weight (estimated) | 0.40 kg |
Mounting and drawing data
drawing (labelled LumaSpec--TP-35): dia 44, length 108
