  • LS-SWL-0156 dimensions (mm)

Thermal, SWIR & UV lenses

70 mm, F8 LWIR Thermal Lens (LS-SWL-0156)

Model LS-SWL-0156

  • Focal length70 mm
  • MountM12
  • ApertureF8
  • TypeThermal (LWIR)
$1,019.00

Ships in 2-3 weeks

0.11 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

70 mm, F8 LWIR Thermal Lens (LS-SWL-0156)LS-SWL-0156

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

70 mm, F8 LWIR Thermal Lens. Long-wavelength infrared (LWIR) thermal lenses designed for commercial and military applications. At a glance: focal length 70 mm; sensor 960X720 6um; aperture F8; mount M12X0.5; distortion 1%.

  • Same-day shipping on stock itemsTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-SWL-0156
Angle of view (deg)4.7(H)x3.53(V)
Front lens coatingMulti-layer coating

Optics

Focal length70 mm
ApertureF8
Distortion1%
Relative illumination0.9
Mechanical back focal length8 mm
Focus methodFixed

Sensor and imaging

Sensor960X720 6um

Mechanical

MountM12X0.5
Dimensionsdia. 14 x L28 mm
Weight<7g
Shipping weight (estimated)0.11 kg

Photo shows a representative model of this series; see the specifications for this model.
