LS-FFL-0736 dimensions (mm)
  • LS-FFL-0736 dimensions (mm)
  • 1", C-mount machine vision lens, 0.3x, WD 510 mm (LS-FFL-0736)

Main picture: this model's dimensioned drawing, from its printed dimensions. The photo shows representative lenses of this series, not this exact model; size and shape differ by model.

Machine vision lenses

1", C-mount machine vision lens, 0.3x, WD 510 mm (LS-FFL-0736)

Model LS-FFL-0736

  • Magnification0.3x
  • MountC-mount
  • Sensor1"
  • Working distance510 mm
  • Aperture11
$309.00

Ships in 2-3 weeks

0.52 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

1", C-mount machine vision lens, 0.3x, WD 510 mm (LS-FFL-0736)LS-FFL-0736

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

LS-FFL-0736: sensor format 1", image-side F/# 11, working distance 510 mm, magnification 0.3x.

1", C-mount Machine Vision Lens. At a glance: magnification 0.3x; working distance 510 mm; max sensor size 16 mm (1"); object-side resolution 24.6 µm; image-side f/# 11.

  • Tracked worldwide shippingTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; no restocking fee
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-FFL-0736

Optics

Magnification (x)0.3
Working distance (mm)510
Image-side F/#11
Object-side telecentricity (deg max)Non-telecentric
Image-side distortion (% max)0.06
Numerical aperture NA0.01363
Object-side resolution (um)24.6
Theoretical depth of field (mm)9.8
Image-side MTF30 (lp/mm)90
Total length TTL (mm)188

Sensor and imaging

Sensor format1"
Max sensor size (dia. mm)16

Mechanical

Outer diameter O.D (mm)dia. 34
MountC
Shipping weight (estimated)0.52 kg

Photo shows a representative model of this series; see the specifications for this model.

Engineering data

Field of view with the LS-FFL-0736

Worked out from this lens's own magnification and image circle: the field it sees on each sensor format.

Image circleØ 16 mmCovers sensors up to 1"
Magnification0.3×
Distortion≤ 0.06 %
Total length188 mm
SizeØ 34 mm
NA0.01363
Depth of field9.8 mmtheoretical
MTF90 lp/mmimage side, at 30 % contrast
Field of view (width × height) by sensor format
Sensor format0.3×
1/1.8"7.07 × 5.3 mm23.6 × 17.7 mm
2/3"8.45 × 7.07 mm28.2 × 23.6 mm
1/1.2"11.25 × 7.03 mm37.5 × 23.4 mm
1"13.2 × 8.8 mm44 × 29.3 mm

Field of view = sensor size ÷ magnification. Sensor sizes are typical for each optical format.

Compatible parts

Fits with this part

Checked with the configurator's fit rules: lens mount and sensor coverage, supply voltage, power per channel and connector.

Build the full system with this part

Cameras this lens fits

7.1 mm sensor diagonal; this lens covers up to 16 mm

9.5 mm sensor diagonal; this lens covers up to 16 mm

3.2 mm sensor diagonal; this lens covers up to 16 mm

6.6 mm sensor diagonal; this lens covers up to 16 mm

With a 5 mm C-CS ring

15.8 mm sensor diagonal; this lens covers up to 16 mm

8.9 mm sensor diagonal; this lens covers up to 16 mm

Adapters

For CS-mount cameras

Other models in the Long working distance standard machine vision lenses (LS-FFL-S96) series

See all 288 models
ModelMagnificationWorking distanceAperturePriceAvailabilityLink
LS-FFL-0736This model0.3x510 mm11$309.00 Ships in 2-3 weeks
LS-FFL-07650.29x200 mm9.5$309.00 Ships in 2-3 weeks View
LS-FFL-07660.29x225 mm9.5$309.00 Ships in 2-3 weeks View
LS-FFL-07280.2x550 mm13.6$309.00 Ships in 2-3 weeks View
LS-FFL-07270.2x590 mm13.5$309.00 Ships in 2-3 weeks View
LS-FFL-07290.2x750 mm12$309.00 Ships in 2-3 weeks View
LS-FFL-07670.36x125 mm14.9$309.00 Ships in 2-3 weeks View
LS-FFL-07300.3x190 mm16.8$309.00 Ships in 2-3 weeks View
LS-FFL-07310.3x216 mm8$309.00 Ships in 2-3 weeks View
LS-FFL-07320.3x300 mm10$309.00 Ships in 2-3 weeks View
LS-FFL-07330.3x340 mm14.1$309.00 Ships in 2-3 weeks View
LS-FFL-07340.3x360 mm12.9$309.00 Ships in 2-3 weeks View
LS-FFL-07350.3x380 mm10$309.00 Ships in 2-3 weeks View
LS-FFL-07370.4x136 mm14.4$309.00 Ships in 2-3 weeks View
LS-FFL-07380.4x250 mm11$309.00 Ships in 2-3 weeks View
LS-FFL-07390.4x650 mm14$309.00 Ships in 2-3 weeks View
LS-FFL-07680.55x140 mm19.6$309.00 Ships in 2-3 weeks View
LS-FFL-07690.55x300 mm13.9$309.00 Ships in 2-3 weeks View
LS-FFL-07400.5x240 mm12.5$309.00 Ships in 2-3 weeks View
LS-FFL-07410.5x375 mm11$309.00 Ships in 2-3 weeks View
LS-FFL-07420.5x660 mm32.8$309.00 Ships in 2-3 weeks View
LS-FFL-07430.5x730 mm35.8$309.00 Ships in 2-3 weeks View
LS-FFL-07440.6x195 mm14.4$309.00 Ships in 2-3 weeks View
LS-FFL-07450.6x220 mm12.9$309.00 Ships in 2-3 weeks View
LS-FFL-07700.71x260 mm17$309.00 Ships in 2-3 weeks View
