20 mm, 0.1x, M42-mount Line Scan Lens (LS-LSL-0179)
  • 20 mm, 0.1x, M42-mount Line Scan Lens (LS-LSL-0179)
  • LS-LSL-0179 dimensions (mm)

Line scan lenses

20 mm, 0.1x, M42-mount Line Scan Lens (LS-LSL-0179)

Model LS-LSL-0179

  • Focal length20 mm
  • MountM42
  • SensorAPS-C
  • ApertureF4.5
  • Resolution4K
$1,429.00

Ships in 2-3 weeks

0.94 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

20 mm, 0.1x, M42-mount Line Scan Lens (LS-LSL-0179)LS-LSL-0179

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

20 mm, 0.1x, M42-mount Line Scan Lens. 20 mm F4.5 line scan lens for 4K cameras with an M42 mount, low distortion (0.2%) and 0.02x-0.1x magnification. For scanning, automation and machine vision. At a glance: focal length 20 mm; format dia. 30 mm (max image); resolution 4K; aperture F4.5; mount M42 x P1.

  • Same-day shipping on stock itemsTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-LSL-0179
Formatdia. 30 mm (max image)
Image distance (mm)14.6±2.5 / 13.3±2.5 / 13.0±2.5
Conjugate distance (mm)261.7±9 / 619.1±9 / 1060.1±9
Image qualityaxis 160 lp/mm, 0.7 field 100 lp/mm

Optics

Focal length20 mm
ApertureF4.5
Magnification / W.D. (mm)0.1X: 198.7±5; 0.0358X: 557.4±5; 0.02X: 998.7±5
Flange focal distance12±0.1 mm
Distortion (TV)0.2%
Relative illumination>50%

Sensor and imaging

Resolution4K

Mechanical

Filter sizeM43 x P0.75
Sizedia. 52 x 48.8 to 51.4 mm
MountM42 x P1
Shipping weight (estimated)0.94 kg
