Machine vision lenses
1/1.8" 5MP FA lens, 50 mm, C-mount (LS-FFL-0590)
Model LS-FFL-0590
- Focal length50 mm
- MountC-mount
- Sensor1/1.8"
- ApertureF2.8-22
- Resolution5MP
- Field of view8.2° x 6.1°
$249.00
Ships in 2-3 weeks
0.38 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
5MP fixed-focal-length industrial FA lens for 1/1.8" sensors, suitable for 2MP, 3MP and 5MP cameras; TV distortion < 0.1%, focal lengths 4 mm to 75 mm, small ultra-compact high-contrast design.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-FFL-0590 |
|---|---|
| F/NO | 2.8-22 |
| EFL | 50mm |
| MOD | 0.3m |
Optics
| Distortion | <0.1% |
|---|---|
| Focal length (mm) | 50 |
| Aperture | F2.8-22 |
| Image size (dia.) | 1/1.8" |
| Field of view angle 1/1.8" | 8.2° x 6.1° |
| Field of view angle 1/2.5" | 6.6° x 4.9° |
| Field of view angle 1/3" | 5.5° x 4.1° |
| Distortion (TV) 1/1.8" | <0.05% |
Sensor and imaging
| Sensor format | 1/1.8" |
|---|---|
| Resolution | 5MP |
Mechanical
| Mount | C-Mount |
|---|---|
| Filter size | M28.5×P0.5 |
| Shipping weight | 0.38 kg |
Other models in the 1/1.8" 5MP FA lens (LS-FFL-S87) series
See all 9 models| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-FFL-0583 | 4 mm, 1/1.8", C-mount | $159.00 | Ships in 2-3 weeks | View |
| LS-FFL-0584 | 6 mm, 1/1.8", C-mount | $169.00 | Ships in 2-3 weeks | View |
| LS-FFL-0585 | 8 mm, 1/1.8", C-mount | $169.00 | Ships in 2-3 weeks | View |
| LS-FFL-0586 | 12 mm, 1/1.8", C-mount | $179.00 | Ships in 2-3 weeks | View |
| LS-FFL-0587 | 16 mm, 1/1.8", C-mount | $189.00 | Ships in 2-3 weeks | View |
| LS-FFL-0588 | 25 mm, 1/1.8", C-mount | $199.00 | Ships in 2-3 weeks | View |
| LS-FFL-0589 | 35 mm, 1/1.8", C-mount | $229.00 | Ships in 2-3 weeks | View |
| LS-FFL-0591 | 75 mm, 1/1.8", C-mount | $309.00 | Ships in 2-3 weeks | View |
