Representative photo of this series
Machine vision lenses
1/1.8" 5MP FA lens, 8 mm, C-mount (LS-FFL-0585)
Model LS-FFL-0585
- Focal length8 mm
- MountC-mount
- Sensor1/1.8"
- ApertureF2.0-C
- Resolution5MP
- Field of view46.8° x 36°
$169.00
In stock - ships the same business day (5 available, order by 2 PM ET)
0.38 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
5MP fixed-focal-length industrial FA lens for 1/1.8" sensors, suitable for 2MP, 3MP and 5MP cameras; TV distortion < 0.1%, focal lengths 4 mm to 75 mm, small ultra-compact high-contrast design.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-FFL-0585 |
|---|---|
| F/NO | 2.0-C |
| EFL | 8mm |
| MOD | 0.1m |
Optics
| Distortion | <0.1% |
|---|---|
| Focal length (mm) | 8 |
| Aperture | F2.0-C |
| Image size (dia.) | 1/1.8" |
| Field of view angle 1/1.8" | 46.8° x 36° |
| Field of view angle 1/2.5" | 38.2° x 29.11° |
| Field of view angle 1/3" | 32.2° x 24.5° |
| Distortion (TV) 1/1.8" | <0.1% |
Sensor and imaging
| Sensor format | 1/1.8" |
|---|---|
| Resolution | 5MP |
Mechanical
| Mount | C-Mount |
|---|---|
| Filter size | M25.5×P0.5 |
| Shipping weight | 0.38 kg |
Other models in the 1/1.8" 5MP FA lens (LS-FFL-S87) series
See all 9 models| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-FFL-0583 | 4 mm, 1/1.8", C-mount | $159.00 | 5 in stock | View |
| LS-FFL-0584 | 6 mm, 1/1.8", C-mount | $169.00 | 4 in stock | View |
| LS-FFL-0586 | 12 mm, 1/1.8", C-mount | $179.00 | 3 in stock | View |
| LS-FFL-0587 | 16 mm, 1/1.8", C-mount | $189.00 | 2 in stock | View |
| LS-FFL-0588 | 25 mm, 1/1.8", C-mount | $199.00 | 5 in stock | View |
| LS-FFL-0589 | 35 mm, 1/1.8", C-mount | $229.00 | 3 in stock | View |
| LS-FFL-0590 | 50 mm, 1/1.8", C-mount | $249.00 | 3 in stock | View |
| LS-FFL-0591 | 75 mm, 1/1.8", C-mount | $309.00 | 4 in stock | View |
