Flat Backlight, 50 x 50 mm, White (LS-BKL-1449)
  • Flat Backlight, 50 x 50 mm, White (LS-BKL-1449)
  • LS-BKL-1449 dimensions (mm)

Backlights

Flat Backlight, 50 x 50 mm, White (LS-BKL-1449)

Model LS-BKL-1449

  • ColourWhite
  • Emitting area50 mm × 50 mm
  • Size82 mm × 63.2 mm × 18 mm
  • Voltage24 VDC
  • Power5.1 W
$209.00
Quote

Quoted price: add to quote for lead time and volume pricing.

End of life soon: the maker is phasing this model out, so stock is limited. Ask us for availability or the successor model.

Ships in 2-3 weeks

0.31 kg shipping weight

Collect parts in your quote list; we reply with price, lead time and volume pricing.

Request a quote

Flat Backlight, 50 x 50 mm, White (LS-BKL-1449)LS-BKL-1449

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

Flat Backlight, 50 x 50 mm, White. Adopts high-density array LED design, and provides excellent lighting uniformity. Provides side mounting lugs to achieve flexible installation.

  • Same-day shipping on stock itemsTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-BKL-1449
Cooling modeNatural cooling

Interfaces and I/O

Connector typeSMR-03V-B
Cable length1 m

Light

ColorWhite
Color temperature6000 ~ 7000K
Center illuminance/irradiance≥ 10000 lux@100 mm
Emitting area dimension50 mm × 50 mm
Diffuse plate includedIncluded

Environment and compliance

TemperatureWorking temperature: 0 °C to 40 °C (32 °F to 104 °F); Storage temperature: –20 °C to 60 °C (–4 °F to 140 °F)
Humidity20% RH to 90% RH (no condensation)

Electrical

Power5.1 W
Input voltage24 VDC

Mechanical

Dimension82 mm × 63.2 mm × 18 mm
Weight0.15 kg
Shipping weight (estimated)0.31 kg
