Flat Backlight, 150 x 100 mm, White (LS-BKL-1465)
  • Flat Backlight, 150 x 100 mm, White (LS-BKL-1465)
  • LS-BKL-1465 dimensions (mm)

Backlights

Flat Backlight, 150 x 100 mm, White (LS-BKL-1465)

Model LS-BKL-1465

  • ColourWhite
  • Emitting area150 mm × 100 mm
  • Size182 mm × 113 mm × 18 mm
  • Voltage24 VDC
  • Power25 W
$319.00
Quote

Quoted price: add to quote for lead time and volume pricing.

End of life soon: the maker is phasing this model out, so stock is limited. Ask us for availability or the successor model.

Ships in 2-3 weeks

0.73 kg shipping weight

Collect parts in your quote list; we reply with price, lead time and volume pricing.

Request a quote

Flat Backlight, 150 x 100 mm, White (LS-BKL-1465)LS-BKL-1465

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

Flat Backlight, 150 x 100 mm, White. Adopts high-density array LED design, and provides excellent lighting uniformity. Provides side mounting lugs to achieve flexible installation.

  • Same-day shipping on stock itemsTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-BKL-1465
Cooling modeNatural cooling

Interfaces and I/O

Connector typeSMR-03V-B
Cable length1 m

Light

ColorWhite
Color temperature6000 ~ 7000K
Center illuminance/irradiance≥ 40000 lux@100 mm
Emitting area dimension150 mm × 100 mm
Diffuse plate includedIncluded

Environment and compliance

TemperatureWorking temperature: 0 °C to 40 °C (32 °F to 104 °F); Storage temperature: –20 °C to 60 °C (–4 °F to 140 °F)
Humidity20% RH to 90% RH (no condensation)

Electrical

Power25 W
Input voltage24 VDC

Mechanical

Dimension182 mm × 113 mm × 18 mm
Weight0.45 kg
Shipping weight (estimated)0.73 kg
