Machine vision lenses
50mm, F1.4, Φ28mm, 900-1700nm, M42 connector, SWIR lens (LS-AF5014M-M42-NIR)
Model LS-AF5014M-M42-NIR
- Focal length50mm
- MountM42
- SensorAPS-C
- Working distance0.43~1 m
- ApertureF1.4
$489.00
In stock - ships the same business day (4 available, order by 2 PM ET)
0.31 kg shipping weight
Volume pricing, Net 30 or a formal quote?
50mm, F1.4, Φ28mm, 900-1700nm, M42 connector, SWIR lens. Maximum sensor format Φ28 mm Large-aperture design for high light throughput
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-AF5014M-M42-NIR |
|---|
Optics
| Focal length | 50mm |
|---|---|
| F-number | F1.4 |
| Image size | Φ28mm |
| Distortion | -1.5% |
| Working distance | 0.43~1 m |
| Field of view | D:30°; H:24°; V:18° |
| Iris control | Manual |
| Focus control | Manual |
| Filter thread | M52×0.75 |
Interfaces and I/O
| Connector type | M42-Mount |
|---|
Environment and compliance
| Temperature | -10 ~ 50°C |
|---|---|
| Certification | RoHS2.0 |
Mechanical
| Flange back length | 12mm |
|---|---|
| Dimension | Φ60 × 99.4~107.4mm |
| Shipping weight (estimated) | 0.31 kg |
