Power supplies
MEAN WELL LRS-75-48 Industrial Power Supply, 48 V 76.8 W
Model LRS-75-48MEAN WELL
- End ATerminal block (220 VAC/DC Input)
- End BTerminal block
- TypePower cords and supplies
- Output power76.8 W max
$35.00
In stock - ships the same business day (2 available, order by 2 PM ET)
0.31 kg shipping weight
Volume pricing, Net 30 or a formal quote?
MEAN WELL LRS-75-48 Industrial Power Supply, 48 V 76.8 W. The industrial power supply adopts terminal blocks as connectors, and can be used to power the device. Multiple specifications are available.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LRS-75-48 |
|---|---|
| Brand | MEAN WELL |
| Packaging | Individual package |
Interfaces and I/O
| End A connector | Terminal block (220 VAC/DC Input) |
|---|---|
| End B connector | Terminal block |
| Applicable scenario | Static |
Environment and compliance
| MTBF | 3, 334, 300 h; (Standard: Telcordia SR-332) |
|---|---|
| Working temperature | –30 °C to 70 °C (–22 °F to 158 °F); (For temperatures above 50 °C, the output load decreases by 2% for every degree increase in temperature.) |
| Certification | CE, UL, CCC, EMC, EAC, TUV, UK |
Electrical
| Input voltage range | 85 VAC ~ 264 VAC; 120 VDC ~ 373 VDC |
|---|---|
| Input AC current | 1.4 A @ 115 VAC; 0.85 A @ 230 VAC |
| Output power | 76.8 W max |
| Output voltage | 48 V |
| Output current | 0 A ~ 1.6 A |
| Overcurrent protection | > 120% of rated current, hiccup mode |
| Overvoltage protection | Overvoltage protection range:; 55.2 V to 64.8 V; Protected mode:; Turn off the output voltage, restart and restore. |
Mechanical
| Shipping weight (estimated) | 0.31 kg |
|---|
