Hikrobot MV-PE5715 Time-of-flight sensor(5m, Infrared Laser, Class1)

Name: Hikrobot MV-PE5715 Time-of-flight sensor(5m, Infrared Laser, Class1)
Brand: Hikrobot
SKU: MV-PE5715

Model MV-PE5715

Hikrobot MV-PE5715 Time-of-flight sensor(5m, Infrared Laser, Class1). Remains unaffected by material and color based on the time-of-flight principle. Provides a teach-in button with ease of use.

Datasheet (PDF) - MV-PE5715 Quick start guide (PDF) - MV-PE5715 CAD: 3D STEP + 2D DXF (ZIP) - MV-PE5715

Features

Remains unaffected by material and color based on the time-of-flight principle.
Provides a teach-in button with ease of use.
Supports light-on/dark-on switch, PNP/NPN switch, and response time switch.

Specifications

Model	MV-PE5715
Brand	Hikrobot
Detecting distance	50 mm to 5000 mm
Sensing target	Standard reflector (100 mm × 100 mm) with reflectivity of 90%
Output	NPN/PNP switch and light-on/dark-on switch
Light source	Infrared laser 905 nm
Response time	500 μs/10 ms switch
Laser safety class	Class 1
Method of setting up	Single teach-in button
Supply voltage	12 VDC to 24 VDC ± 10%
Residual voltage	≤ 2 VDC
Operating current	≤ 35 mA @ 12V, ≤ 20 mA @ 24V
Max. sink/source current	≤ 100 mA
Circuit protection	Reverse polarity protection, overcurrent protection, and overvoltage protection
Insulation resistance	20 MΩ or more (between the terminal block for power supply and the housing)
Withstand voltage	1000 VAC, 1 min (between the terminal block for power supply and the housing)
Dimension	20 mm × 12 mm × 31.6 mm (0.8" × 0.5" × 1.2")
Weight	Approx. 45 g (0.1 lb.) (including cable)
Temperature	Working temperature: –25 °C to 55 °C (–13 °F to 131 °F); Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F)
Humidity	35% RH to 85% RH
Ambient illumination	Sunlight: < 10000 lux; Incandescent lamp: < 3000 lux
Ingress protection	IP67
Material	Housing: polycarbonate; Lens: acrylic
Indicator	Operation indicator: orange; Stability indicator: green
Connecting method	Cable lead-out (standard length: 2 m, 78.7")
Vibration resistance	10 Hz to 500 Hz, double amplitude 1.5 mm (0.1"), 2 hours in each of the X, Y, and Z directions
Shock resistance	500 m/s2, 3 times in each of the X, Y, and Z directions
Certification	CE, RoHS
Shipping weight (estimated)	0.16 kg
