Hikrobot MV-CI010-GS-NN 1k SWIR line-scan, GigE, Fanless
Model MV-CI010-GS-NN
Hikrobot MV-CI010-GS-NN 1k SWIR line-scan, GigE, Fanless. InGaAs sensor with 0.9–1.7 µm broad-spectrum imaging, large 12.5 µm pixels and high dynamic range Compact camera body fits tight spaces in industrial equipment
Datasheet (PDF, Chinese) - MV-CI010-GS-NNUser manual (PDF, Chinese) - MV-CI010-GS-NNCAD: 3D STEP + 2D DXF (ZIP) - MV-CI010-GS-NN
Features
- InGaAs sensor with 0.9–1.7 µm broad-spectrum imaging, large 12.5 µm pixels and high dynamic range
- Compact camera body fits tight spaces in industrial equipment
- Rich ISP functions, including ADC and contrast adjustment
- Gigabit Ethernet interface: up to 100 m transmission without a repeater
- Compatible with GigE Vision V2.0 and the GenICam standard for seamless connection to third-party software
Specifications
| Model | MV-CI010-GS-NN |
|---|---|
| Brand | Hikrobot |
| Sensor type | InGaAs |
| Pixel size | 12.5 μm × 12.5 μm |
| Resolution | 1024 × 1 |
| Pixel format | Mono 8/10/12/14 |
| Max. line rate | 15 kHz @1024 × 1 Mono 8 |
| Dynamic range | 69.8 dB |
| SNR | 46.6 dB |
| External trigger mode | Line trigger, frame trigger, line + frame trigger |
| Data interface | Gigabit Ethernet(1000Mbit/s) |
| Power supply | 12 VDC |
| Digital I/O | 12-pin P10 connector provides power and I/O: 1 single-ended frame trigger input, 1 single-ended line trigger input, 1 differential line trigger input (RS422 level) |
| Power consumption | 5.0 W@12 VDC |
| Dimension | 53 mm × 60 mm × 61.2 mm (incl. lens mount) |
| Weight | Approx. 355 g |
| Ingress protection | IP40 (under proper lens installation and wiring) |
| Temperature | Working temperature: –10 °C to 50 °C (14 °F to 122 °F); Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F) |
| Humidity | 20% RH to 95% RH (no condensation) |
| Lens mount | C-Mount |
| Client software | MVS or third-party software meeting with GigE Vision Protocol |
| Operating system | Windows 7/10 32/64bits, Windows 11 64bits, Linux 32/64bits |
| Compatibility | GigE Vision 2.0, GenICam |
| Certification | CE, RoHS |
| Shipping weight (estimated) | 0.60 kg |
