Megapixel telecentric lens (VWH), 0.3x, WD 110 mm, 1/1.8", C-Mount (LS-VWH03-110CT)

Name: Megapixel telecentric lens (VWH), 0.3x, WD 110 mm, 1/1.8", C-Mount (LS-VWH03-110CT)
Brand: LumaSpec Vision
SKU: LS-VWH03-110CT
Price: 969.00 USD
Availability: InStock

Model LS-VWH03-110CT

Megapixel 'object side' telecentric lens with a compact design and coaxial illumination options; high contrast, low distortion and high resolution, with optional adjustable iris and long working distance versions over 500 mm.

Datasheet (PDF) - LS-VWH03-110CT

Features

Compact design with coaxial illumination options
Supports all kinds of megapixel cameras
High contrast, low distortion, high resolution
Optional adjustable iris for resolution and DOF control
Megapixel 'object side' telecentric lens with optional long working distance versions with over 500mm working distance
Perfect image and supports all kinds of Mega camera
Optional adjustable Iris for resolution and DOF control

Specifications

Model	LS-VWH03-110CT
Mount	C
Magnification(x)	0.3
Working Distance (mm)	110±2
Max Sensor Size (dia. mm)	9.0(1/1.8")
Aperture (F/#)	9
Distortion typical (max) (%)	0.1
MTF30 (lp/mm)	100
NA	0.0167
Resolution (um)	20.1
Depth of Field (mm)	8.0
FOV with 7.16x 5.44 with ICX274/687 (mm x mm)	23.9x18.1
FOV with 7.2x 5.4 with EV76C570 (mm x mm)	24.0x18.0
Length (mm)	137.1
Coaxial Light	Yes
Iris	No
Mount (product parameters)	C-Mount
Detector	9.0(1/1.8")
Magnification (product parameters)	0.3x
WD (product parameters)	110mm
Magnification (x)	0.3
Telecentricity typical (max) (deg)	<0.1
MTF30(lp/mm)	100
Field of view with ICX274/687 (7.16x5.44 sensor) (mm x mm)	23.9x18.1
Field of view with EV76C570 (7.2x5.4 sensor) (mm x mm)	24.0x18.0
Sensor format	1/1.8"
Shipping weight	0.75 kg

Complete the station

The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.

Configure a system Selection guide
