0.267x telecentric lens, 1", C-mount (LS-TCL-0033)

Rendered illustration: the actual product may differ in appearance.

Telecentric lenses

0.267x telecentric lens, 1", C-mount (LS-TCL-0033)

Model LS-TCL-0033

Telecentric lens with constant magnification across the depth of field, for measurement and gauging without perspective error. Connection: flying leads.

Datasheet (PDF) - LS-TCL-0033 3D model (STEP) - LS-TCL-0033

Specifications

Model	LS-TCL-0033
Magnification	0.267x
Sensor format	1"
Mount	C-mount
Connector	Flying Leads
Dimensions approximate	200.8 x 111 x 281 mm
Filter thread	No Filter Threads
Fov maximum	7
Image size dimensions	14.2 x 7.5 mm
LED current	280 mA
LED voltage	36 Volts
Lens type	Bi-Telecentric
Light color	White
Operating relative humidity (%)	20-85 Non Condensing
Operating temperature range	0 to 40°C
Power consumption maximum	6.7 Watts
Pulse current maximum	3 mA
Storage temperature range	0 to 50°C
Supply voltage	24 Volts
Working ƒ/n	f/16
Weight	2229 Grams
