Rendered illustration: the actual product may differ in appearance.
Telecentric lenses
0.303x telecentric lens, 1.1", C-mount (LS-TCL-0023)
Model LS-TCL-0023
Telecentric lens with constant magnification across the depth of field, for measurement and gauging without perspective error. Connection: flying leads.
Specifications
| Model | LS-TCL-0023 |
|---|---|
| Magnification | 0.303x |
| Sensor format | 1.1" |
| Mount | C-Mount |
| Connector | Flying Leads |
| Dimensions approximate | 200.8 x 111 x 270.7 mm |
| Filter thread | No Filter Threads |
| Fov maximum | 5 |
| Image size dimensions | 14.2 x 10.4 mm |
| LED current | 280 mA |
| LED voltage | 36 Volts |
| Lens type | Bi-Telecentric |
| Light color | White |
| Operating relative humidity (%) | 20-85 Non Condensing |
| Operating temperature range | 0 to 40°C |
| Power consumption maximum | 6.7 Watts |
| Pulse current maximum | 3 mA |
| Storage temperature range | 0 to 50°C |
| Supply voltage | 24 Volts |
| Working ƒ/n | f/16 |
| Weight | 2171 Grams |
