Rendered illustration: the actual product may differ in appearance.
Telecentric lenses
0.068x telecentric lens, 1/2", C-mount (LS-TCL-0027)
Model LS-TCL-0027
Telecentric lens with constant magnification across the depth of field, for measurement and gauging without perspective error. Connection: flying leads / m8.
Specifications
| Model | LS-TCL-0027 |
|---|---|
| Magnification | 0.068x |
| Sensor format | 1/2" |
| Mount | C-Mount |
| Connector | Flying Leads / M8 |
| Dimensions approximate | 347 x 179 x 404.4 mm |
| Filter thread | No Filter Threads |
| Fov maximum | 16 |
| Image size dimensions | 6.4 x 4.8 mm |
| LED current | 620 mA |
| LED voltage | 36 Volts |
| Lens type | Bi-Telecentric |
| Light color | White |
| Operating relative humidity (%) | 20-85 Non Condensing |
| Operating temperature range | 0 to 40°C |
| Power consumption maximum | 14.9 Watts |
| Pulse current maximum | 6 mA |
| Storage temperature range | 0 to 50°C |
| Supply voltage | 24 Volts |
| Working ƒ/n | f/8 |
| Weight | 6912 Grams |
