Line scan camera (V-generation), 4K, 10GigE, Color (LS-MV-L043C-DG-V1)
Model LS-MV-L043C-DG-V1
This 2K line scan cameras adopts GigE interface and with a maximum line frequency of 120K.
Features
- 7um-sized pixel.
- Flat-field supports writing and storing multiple sets of camera parameters.
- Built-in large-capacity frame buffer, safe and reliable verification and repair technology to ensure transmission.
- Software is compatible with GigEVision and GenlCam protocols.
Specifications
| Model | LS-MV-L043C-DG-V1 |
|---|---|
| Resolution | 4096*3 |
| Sensor | 4K |
| Pixel size | 7um |
| Line frequency | 23k |
| Data Interface | 2.5GigE |
| Lens Mount | M42 |
| Color/Mono | Color |
| Color | Color |
| Target size | 28mm |
| Shutter | Global |
| Resolution (product page) | 4096×3 |
| Imaging mode | 3 line |
| Dynamic range | 65dB |
| Exposure Time | 3.6us -- 40ms, 1us steps |
| Exposure Mode | Support manual exposure/single exposure/automatic exposure/pulse width control exposure |
| Gain | 1x-16x,0.25x adjustable step |
| Pixel format | RGB8BGR8BayerGR8 |
| Trigger Mode | Row triggered, frame triggered, row + frame triggered |
| I/O Interface | 1 channel frame signal input (support RS422 standard differential and 3.3V-24V single-ended signal),2 line signal input (support RS422 standard differential and 3.3V-24V single-ended signal),2 differential outputs or 4 single-ended outputs (output level 5V/12V),Can be multiplexed to 3 inputs (1 differential input and 2 single-ended inputs) |
| Power supply | DC12V-24V (±10%) |
| Typical Power Consumption | 4.5W@24VDC |
| Lens Interface | M42*1 |
| IO and Power Interface | 12 core industrial circular connector |
| Filter | 380nm-650nm bandpass filter |
| Dimension | 62mm×62mm×36.8mm |
| Weight | Approx.220g |
| IP Protection Rating | IP40 (with lens and cable properly installed) |
| Temperature | Operating temperature:10℃~45℃, Storage temperature:-20℃ ~ 70℃ |
| Humidity | 5% ~ 90%RH (non-condensing) |
| Software | SDK development kit, and related demonstration/calibration software BasedCam3 |
| Operating Systems | Windows7/10 64bits,PC Linux 64bits, ARM Linux |
| Protocols/Standards | GigE Vision 1.2, GenICam |
| Compatible Software | OpenCV, LabView, Halcon |
| Certifications | CE,RoHS |
| Mono / colour | Color |
| Voltage | DC12V-24V (±10%) |
