Representative photo of this series
Line scan lights
Natural cooling line scan light, 840 x 50 x 95 mm (LS-LSC-0298)
Model LS-LSC-0298
- ColourWhite
- Emitting area800 x 18 mm
- SizeL840xW50xH95(mm)
- Voltage24 V
- Power192 W
Ships in 2-3 weeks
2.75 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
LS-LSC-0298: dimension L840xW50xH95(mm), emitting surface 800 x 18 mm, power 192 W.
Use high-standard LED design optics to achieve high uniformity and high brightness imaging effect. Dustproof and no fan design, suitable for dusty environments. Suitable for semiconductor, LCD manufacturing process and other applications, can achieve high-speed strobe mode.
- Tracked worldwide shippingTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; no restocking fee
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-LSC-0298 |
|---|---|
| Cooling | Natural Cooling |
| Note | UV & IR light can be customized as required. |
Interfaces and I/O
| Cable polarity | 1: +, 2: -, 3: NC, 4: NC |
|---|---|
| Cable (mm) | 3000 (drawing) |
Light
| LED colour | R(red)/W(white) |
|---|---|
| Emitting surface (mm) | 800 x 18 |
Electrical
| Voltage | 24 V |
|---|---|
| Power | 192 W |
| Input voltage | DC 24 V (max) |
Mechanical
| Dimension | L840xW50xH95(mm) |
|---|---|
| Mounting holes | 4 x M4 nut slots |
| Mounting | M4 nut slots on all sides for mounting |
| Shipping weight | 2.75 kg |
Engineering data
Drive and fit the LS-LSC-0298
Worked out from the printed voltage, power and dimensions: what the light draws and what it needs from a controller.
Mounting and installation
| Mounting | T-slot / nut channelSlots take M4 nuts |
|---|---|
| Cable | 3 m |
As printed in this model's specifications and dimension drawing. Check the drawing in Downloads before you drill a fixture.
Compatible parts
Fits with this part
Checked with the configurator's fit rules: lens mount and sensor coverage, supply voltage, power per channel and connector.
Controllers for this light
240 W per channel at 24 V for this 192 W light
200 W per channel at 24 V for this 192 W light
200 W per channel at 24 V for this 192 W light
Digital Light Controller, 6 channel, 90 W/24 V
LS-CTL-0291
- Output 24 VDC
- Input 24 VDC
$229.00
Ships in 2-3 weeks
Same 24 V supply
Digital controller, 8 ch, 2.5 A total output
LS-CTL-0353
- Channels 8
- Output 16-24 V
$429.00
Ships in 2-3 weeks
Same 24 V supply
Same 24 V supply
Application studies
Applications for this type of part
Real camera images from lighting and optics application tests, with the parts of each setup and why they were chosen.
Set up with the LS-LSC-0293, a model of this series
Metal parts and machining
A line-scan station for metal surface scratches
The lighting reveals the feature; synchronized material travel turns the line into a useful image.Proposed camera2048 pixels · monoExplore the study
Other models in the Natural cooling line scan light (LS-LSC-S31) series
See all 10 models| Model | Emitting area | Size | Power | Price | Availability | Link |
|---|---|---|---|---|---|---|
| LS-LSC-0298This model | 800 x 18 mm | L840xW50xH95(mm) | 192 W | $2,459.00 | Ships in 2-3 weeks | |
| LS-LSC-0291 | 100 x 18 mm | L140xW50xH95(mm) | 24 W | $569.00 | Ships in 2-3 weeks | View |
| LS-LSC-0292 | 200 x 18 mm | L240xW50xH95(mm) | 48 W | $839.00 | Ships in 2-3 weeks | View |
| LS-LSC-0293 | 300 x 18 mm | L340xW50xH95(mm) | 72 W | $1,109.00 | Ships in 2-3 weeks | View |
| LS-LSC-0294 | 400 x 18 mm | L440xW50xH95(mm) | 96 W | $1,379.00 | Ships in 2-3 weeks | View |
| LS-LSC-0295 | 500 x 18 mm | L540xW50xH95(mm) | 120 W | $1,649.00 | Ships in 2-3 weeks | View |
| LS-LSC-0296 | 600 x 18 mm | L640xW50xH95(mm) | 144 W | $1,919.00 | Ships in 2-3 weeks | View |
| LS-LSC-0297 | 700 x 18 mm | L740xW50xH95(mm) | 168 W | $2,189.00 | Ships in 2-3 weeks | View |
| LS-LSC-0299 | 900 x 18 mm | L940xW50xH95(mm) | 216 W | $2,729.00 | Ships in 2-3 weeks | View |
| LS-LSC-0300 | 1000 x 18 mm | L1040xW50xH95(mm) | 240 W | $2,999.00 | Ships in 2-3 weeks | View |
