USB3.0 area scan camera, 1.6 MP, Color/Mono (LS-CMR-0473)
  • USB3.0 area scan camera, 1.6 MP, Color/Mono (LS-CMR-0473)

Representative photo of this series

Area scan cameras

USB3.0 area scan camera, 1.6 MP, Color/Mono (LS-CMR-0473)

Model LS-CMR-0473-Color

  • Resolution1480*1092
  • InterfaceUSB3.0
  • Speed240FPS
  • Lens mountC-mount
  • Pixel size4.0 μm
$389.00

Ships in 2-3 weeks

0.59 kg shipping weight

Sensor

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

USB3.0 area scan camera, 1.6 MP, Color/Mono (LS-CMR-0473)LS-CMR-0473-Color

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

LS-CMR-0473: resolution 1480 x 1092, sensor 1/2.2", frame rate 240FPS, pixel size 4.0 µm.

This series of USB3.0 area scan cameras includes color and monochrome, global and rolling shutter.Fastest transmission speed reaches 440MByte/s.

  • Tracked worldwide shippingTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; no restocking fee
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-CMR-0473

Sensor and imaging

Resolution1480*1092
Pixel size4.0 μm
ShutterGlobal
Frame rate240FPS
Sensor1/2.2"

Interfaces and I/O

Data interfaceUSB3.0

Light

Mono / colourColor/Mono

Mechanical

Target size1/2.2"
Lens mountC
Shipping weight0.59 kg

Engineering data

Field of view and resolution with the LS-CMR-0473

Worked out from this camera's own sensor: the field of view and the size one pixel covers on the part, for common lenses and working distances.

Sensor area5.92 × 4.37 mm1/2.5" optical format
Lens image circle needed≥ Ø 7.4 mmC-mount
Pixel pitch4 µm1480 x 1092 px
Image data at max frame rate388 MB/sCalculated: 240 fps × 1480 × 1092 px at 8 bit · USB3 carries 625 MB/s nominal
With a 16 mm lens at 500 mm185 × 137 mm0.125 mm per pixel
ShutterGlobal
Field of view (width × height) and object pixel size by lens focal length and working distance
LensAt 300 mmAt 500 mmAt 1000 mm
8 mm222 × 164 mm0.15 mm per pixel370 × 273 mm0.25 mm per pixel740 × 546 mm0.5 mm per pixel
12 mm148 × 109 mm0.1 mm per pixel247 × 182 mm0.167 mm per pixel493 × 364 mm0.333 mm per pixel
16 mm111 × 81.9 mm0.075 mm per pixel185 × 137 mm0.125 mm per pixel370 × 273 mm0.25 mm per pixel
25 mm71 × 52.4 mm0.048 mm per pixel118 × 87.4 mm0.08 mm per pixel237 × 175 mm0.16 mm per pixel
35 mm50.7 × 37.5 mm0.034 mm per pixel84.6 × 62.4 mm0.057 mm per pixel169 × 125 mm0.114 mm per pixel
50 mm35.5 × 26.2 mm0.024 mm per pixel59.2 × 43.7 mm0.04 mm per pixel118 × 87.4 mm0.08 mm per pixel

Thin-lens approximation: field of view ≈ sensor size × working distance ÷ focal length. Object pixel size = field-of-view width ÷ horizontal pixels; a feature should span about 3-4 pixels to be measured reliably.

Compatible parts

Fits with this part

Checked with the configurator's fit rules: lens mount and sensor coverage, supply voltage, power per channel and connector.

Build the full system with this part

Lenses for this C-mount camera

Covers up to 9.5 mm diagonal; this camera's sensor is 7.4 mm

Covers up to 9.5 mm diagonal; this camera's sensor is 7.4 mm

Covers up to 9.5 mm diagonal; this camera's sensor is 7.4 mm

Covers up to 9.5 mm diagonal; this camera's sensor is 7.4 mm

Covers up to 9.5 mm diagonal; this camera's sensor is 7.4 mm

Covers up to 9.5 mm diagonal; this camera's sensor is 7.4 mm

Cables and frame grabbers

Other models in the USB3.0 area scan camera (LS-CMR-S36) series

See all 17 models
ModelResolutionSpeedPixel sizePriceAvailabilityLink
LS-CMR-0473This model1480*1092240FPS4.0 μm$389.00 Ships in 2-3 weeks
LS-CMR-04752048*1200170FPS4.0 μm$179.00 Ships in 2-3 weeks View
LS-CMR-0469640*480721FPS4.0 μm$219.00 Ships in 2-3 weeks View
LS-CMR-0470640*480721FPS4.0 μm$219.00 Ships in 2-3 weeks View
LS-CMR-0468640 × 480721FPS4.0 μm×4.0 μm$219.00 Ships in 2-3 weeks View
LS-CMR-04762592*194431FPS2.2 μm$239.00 Ships in 2-3 weeks View
LS-CMR-04783072*204871FPS2.4 μm$269.00 Ships in 2-3 weeks View
LS-CMR-04793840*216050.6FPS2.0 μm$269.00 Ships in 2-3 weeks View
LS-CMR-04711280*1024213FPS4.0 μm$359.00 Ships in 2-3 weeks View
LS-CMR-04721280*1024257FPS4.0 μm$359.00 Ships in 2-3 weeks View
LS-CMR-04804000*300035.9FPS1.85 μm$379.00 Ships in 2-3 weeks View
LS-CMR-04741920*120040FPS5.86 μm$469.00 Ships in 2-3 weeks View
LS-CMR-04845480*364822FPS2.4 μm$569.00 Ships in 2-3 weeks View
LS-CMR-04772448*204885FPS3.4 μm$689.00 Ships in 2-3 weeks View
LS-CMR-04814096*307231FPS3.2 μm$1,769.00 Ships in 2-3 weeks View
LS-CMR-04824096*307231.9FPS3.4 μm$1,769.00 Ships in 2-3 weeks View
LS-CMR-04834096*307231.9FPS3.4 μm$1,769.00 Ships in 2-3 weeks View
