90 x 32 mm Bar light (LS-BAR-0829)
  • 90 x 32 mm Bar light (LS-BAR-0829)
  • LS-BAR-0829 dimensions (mm)

Representative photo of this series

Bar lights

90 x 32 mm Bar light (LS-BAR-0829)

Model LS-BAR-0829-R

  • ColourRed, Green, Blue, White
  • Emitting area90 x 32 mm
  • TypeStandard
  • Cable length500 mm
$209.00

Ships in 2-3 weeks

0.3 kg shipping weight

Color

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

90 x 32 mm Bar light (LS-BAR-0829)LS-BAR-0829-R

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

LS-BAR-0829: size L 102 x W 38 mm, emitting area 90 x 32 mm, LED rows 6, power green / blue / white 7.0 W.

Bar lights are especially suited to imaging large features; lengths range from a dozen-odd millimetres to several metres and the light colour is chosen as needed. Several bar lights can be combined freely and the illumination angle adjusted to the inspection. (Length can be customised: length = 57 + 45 x N; above 1002 mm splicing is recommended.)

  • Tracked worldwide shippingTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; no restocking fee
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-BAR-0829
Expected lifeRed and white: 30000 h continuous, decays to 50% (typical one-year decay 8-15%); blue and green: 30000 h continuous, decays to 60% (typical one-year decay 10-18%)
Support1 year of free standard technical support; can be customised to the inspected feature, working distance, illumination angle and field of view

Interfaces and I/O

Cable length (mm)500

Light

LED rows6
Emitting area (mm)90 x 32
Wavelength red620-630 nm
Wavelength green525 nm
Wavelength blue470 nm
Colour temperature white5000-8000 K

Environment and compliance

Operating environmentAmbient about 25 °C, operating temperature within 35 °C

Electrical

Recommended controllersLS-CTL-0140, -2T / LS-CTL-0142 / LS-CTL-0526, -4T / LS-CTL-0333, -4T, -6T, -8T
Power, green / blue / white (W)7.0
Power, red (W)4.5
Supply voltage (derived)24 V DC, derived from the 24 V output of its recommended controllers LS-CTL-0140, LS-CTL-0142, LS-CTL-0526, LS-CTL-0333

Mechanical

Mounting2 x 2-M3 threads, depth 5 (per drawing)
Size (mm)L 102 x W 38
Height (mm)27
Shipping weight0.30 kg

Engineering data

Drive and fit the LS-BAR-0829

Worked out from the printed voltage, power and dimensions: what the light draws and what it needs from a controller.

Supply24 V DC
Current at 24 V292 mACalculated: printed power ÷ supply voltage
Controller channel it needs24 V constant voltage, at least 7 W
Emitting length90 mm
Cable length500 mm

Mounting and installation

Mounting holes 2 × 2 × M3 (4 holes)5 mm deep
Cable0.5 m

As printed in this model's specifications and dimension drawing. Check the drawing in Downloads before you drill a fixture.

Compatible parts

Fits with this part

Checked with the configurator's fit rules: lens mount and sensor coverage, supply voltage, power per channel and connector.

Build the full system with this part

Controllers for this light

Recommended

Same 24 V supply

Recommended

Same 24 V supply

Recommended

Same 24 V supply

Recommended

Same 24 V supply

10 W per channel at 24 V for this 7 W light

8.1 W per channel at 24 V for this 7 W light

Other models in the Bar light (LS-BAR-S85) series

See all 66 models
ModelSizeEmitting areaPriceAvailabilityLink
LS-BAR-0829This model90 x 32 mm90 x 32 mm$209.00 Ships in 2-3 weeks
LS-BAR-082445 x 12 mm45 x 12 mm$149.00 Ships in 2-3 weeks View
LS-BAR-082545 x 22 mm45 x 22 mm$149.00 Ships in 2-3 weeks View
LS-BAR-082645 x 32 mm45 x 32 mm$149.00 Ships in 2-3 weeks View
LS-BAR-082790 x 12 mm90 x 12 mm$209.00 Ships in 2-3 weeks View
LS-BAR-082890 x 22 mm90 x 22 mm$209.00 Ships in 2-3 weeks View
LS-BAR-0830135 x 12 mm135 x 12 mm$259.00 Ships in 2-3 weeks View
LS-BAR-0831135 x 22 mm135 x 22 mm$259.00 Ships in 2-3 weeks View
LS-BAR-0832135 x 32 mm135 x 32 mm$259.00 Ships in 2-3 weeks View
LS-BAR-0833180 x 12 mm180 x 12 mm$279.00 Ships in 2-3 weeks View
LS-BAR-0834180 x 22 mm180 x 22 mm$279.00 Ships in 2-3 weeks View
LS-BAR-0835180 x 32 mm180 x 32 mm$279.00 Ships in 2-3 weeks View
LS-BAR-0839270 x 12 mm270 x 12 mm$299.00 Ships in 2-3 weeks View
LS-BAR-0840270 x 22 mm270 x 22 mm$299.00 Ships in 2-3 weeks View
LS-BAR-0841270 x 32 mm270 x 32 mm$299.00 Ships in 2-3 weeks View
LS-BAR-0842315 x 12 mm315 x 12 mm$339.00 Ships in 2-3 weeks View
LS-BAR-0843315 x 22 mm315 x 22 mm$339.00 Ships in 2-3 weeks View
LS-BAR-0844315 x 32 mm315 x 32 mm$339.00 Ships in 2-3 weeks View
LS-BAR-0836225 x 12 mm225 x 12 mm$359.00 Ships in 2-3 weeks View
LS-BAR-0837225 x 22 mm225 x 22 mm$359.00 Ships in 2-3 weeks View
LS-BAR-0838225 x 32 mm225 x 32 mm$359.00 Ships in 2-3 weeks View
LS-BAR-0845360 x 12 mm360 x 12 mm$379.00 Ships in 2-3 weeks View
LS-BAR-0846360 x 22 mm360 x 22 mm$379.00 Ships in 2-3 weeks View
LS-BAR-0847360 x 32 mm360 x 32 mm$379.00 Ships in 2-3 weeks View
LS-BAR-0848405 x 12 mm405 x 12 mm$519.00 Ships in 2-3 weeks View
