Hikrobot MV-ID2020RM-16M-RBN-U 2 MP rolling shutter, 16 mm focal length, Autofocus, Red light, USB, Semi-polarized smart code reader

Model MV-ID2020RM-16M-RBN-UHikrobot

Resolution1920 × 1080
InterfaceUSB 2.0 (separate DC power required)
Speed50 fps
Lens mountM12
Focal length16 mm

$709.00

Ships in 2-3 weeks

0.24 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Hikrobot MV-ID2020RM-16M-RBN-U 2 MP rolling shutter, 16 mm focal length, Autofocus, Red light, USB, Semi-polarized smart code reader. Highly robust algorithm accurately reads difficult codes: damaged, skewed, low-contrast and laser-etched on metal Advanced integrated image processing, 4-zone independent light control and a range of optical accessories for sharper code detail

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our licensed P.E. engineers
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items; free return label in the US
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	MV-ID2020RM-16M-RBN-U
Brand	Hikrobot
Lens cap	Semi-polarizing lens cover, Clear optional, Full-polarized, ESD protective cover
Indicator	Power indicator (PWR), network indicator (LNK), result indicator (OK/NG), user-defined indicator (U1)

Optics

Focal length	16 mm
Field of view	19° (H) × 11° (V)

Sensor and imaging

Symbologies	1D codes: Code 39, Code 93, Code 128 (GS1-128 included), CodaBar, EAN 8, EAN 13, UPCA, UPCE; ITF 14, ITF 25, Matrix 25, MSI, China Post, Code 11, Industrial 2of5, and Pharmacode (one/two-track); 2D matrix codes: QR Code (GS1-QR included), Data Matrix (GS1-DM included), MicroQR, AZTEC, HanXin, Maxi code; Stacked codes: PDF417, MicroPDF417
Max. frame rate	50 fps
Max. reading speed	80 codes/s
Sensor type	Rolling shutter, Mono, 1/2.8", 2.9 μm x 2.9 μm
Resolution	1920 × 1080
Exposure time	60 μs to 100 ms (max. exposure time 59600 μs with HDR on)
Gain	0 dB to 48 dB (max. gain 24 dB with HDR on)
Aiming system	2 green LED lights

Interfaces and I/O

Data interface	USB 2.0 (separate DC power required)
Communication protocol	USB 2.0 (with DC power supply)
Digital I/O	17-pin M12 connector provides power and I/O, including isolated input (LineIn 0/1) × 2, isolated output (LineOut 3/4) × 2, RS-232 × 1. Supports device triggering and factory reset via pressing side button.
Client software	IDMVS

Light

Light source	Red as standard (620 nm to 632 nm), optional white (6500 K), Blue (464 nm to 476 nm), red/blue dual-color (620 nm to 632 nm & 464 nm to 476 nm), infrared (840 nm to 870 nm), ultraviolet (360 nm to 370 nm)

Environment and compliance

Ingress protection	IP65
Temperature	Working temperature: 0 °C to 50 °C (32 °F to 122 °F); Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F)
Humidity	20% RH to 95% RH (no condensation)
Vibration resistance	Device only: 10 Hz to 55 Hz, 1.5 mm full amplitude, 2 hours per axis (X/Y/Z) (IEC 60068-2-6:2007\GB/T 2423.10-2019)
Shock resistance	Device only, 30 g / 11 ms, half-sine wave, 500 shocks per axis (6 directions) (IEC 60068-2-27\GB/T 2423.5-2019)
Certification	CE, RoHS, KC

Electrical

Power supply	24 VDC
Power consumption	Avg.: 5 W @ 24 VDC (light source enabled); Max.: 12 W @ 24 VDC (light source enabled)

Mechanical

Lens mount	M12-Mount, Mechanical focus adjustable
Shell material	Aluminum alloy
Dimension	Straight angle: 72.7 mm × 31.5 mm × 41 mm (2.9" × 1.2" × 1.6"); Right angle: 51.5 mm × 31.5 mm × 61 mm (2.0" × 1.2" × 2.4")
Weight	100 g
Shipping weight (estimated)	0.24 kg

Downloads

Features

Highly robust algorithm accurately reads difficult codes: damaged, skewed, low-contrast and laser-etched on metal
Advanced integrated image processing, 4-zone independent light control and a range of optical accessories for sharper code detail
Modular assembly, rotatable tail cable, separable cables and multi-side mounting interfaces for tight spaces
Multiple isolated I/O channels and industrial protocols for seamless integration with automation systems
With the IDMVS client: autofocus, one-click tuning and more for fast, easy setup

Complete the station

The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.

Build a system with this part Configure a system Ask an engineer
