Hikrobot MV-CT2CG0050/G/NN/NN 5MP Area Scan Camera, 3rd Gen., GigE, Color, MAX
  • Hikrobot MV-CT2CG0050/G/NN/NN 5MP Area Scan Camera, 3rd Gen., GigE, Color, MAX
  • MV-CT2CG0050/G/NN/NN dimensions (mm)

Area scan cameras

Hikrobot MV-CT2CG0050/G/NN/NN 5MP Area Scan Camera, 3rd Gen., GigE, Color, MAX

Model MV-CT2CG0050/G/NN/NNHikrobot

  • Resolution2448 × 2048
  • SensorCMOS, global shutter
  • Lens mountC-mount
  • Mono / colourColor
  • Pixel size3.45 μm × 3.45 μm
$819.00

Ships in 2-3 weeks

0.27 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Ask an engineerBrowse Area scan cameras

MV-CT2CG0050/G/NN/NN: resolution 2448 x 2048; sensor type CMOS, global shutter; sensor size 2/3"; data interface type 8-pin M12 X-Code waterproof aviation connector; mono/color Color.

Hikrobot MV-CT2CG0050/G/NN/NN 5MP Area Scan Camera, 3rd Gen., GigE, Color, MAX. The devices with PRO version and MAX version support waterproof connector. The devices with PRO version and MAX version adopt precision temperature control design for fast heat balance.

  • Tracked worldwide shippingTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; no restocking fee
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Certifications (as printed)CERoHSKC

Specifications

General

ModelMV-CT2CG0050/G/NN/NN
BrandHikrobot
CompatibilityGigE Vision V2.0, GenICam

Sensor and imaging

Sensor typeCMOS, global shutter
Sensor modelStacked BSI
Pixel size3.45 μm × 3.45 μm
Sensor size2/3"
Resolution2448 × 2048
Max. frame rate24.5 fps @ 2448 × 2048 Bayer GR 8; 59.2 fps @ 2448 × 2048 Bayer GR 8 (lossless compression mode enabled)
Dynamic range73.9 dB
SNR42.4 dB
GainHigh full well capacity: 0 dB to 12.8 dB; High sensitivity: 0 dB to 24 dB
Exposure timeHigh full well capacity: 30 μs to 10 sec; High sensitivity: 5 μs to 10 sec
Exposure modeOff/Once/Continuous exposure mode, supports Trigger Width and Trigger Controlled
Pixel formatMono 8; Bayer GR 8/10/10Packed/12/12Packed, YUV422Packed, YUV422_YUYV_Packed; RGB 8, BGR 8
Mono/colorColor
BinningSupports 1 × 1, 2 × 2, 4 × 4
DecimationSupports 1 × 1, 2 × 2, 4 × 4
Reverse imageSupports horizontal and vertical reverse image output

Interfaces and I/O

Data interfaceGigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s)
Data interface type8-pin M12 X-Code waterproof aviation connector
Control interface8-pin M12 A-Code waterproof aviation connector
Digital I/O8-pin M8 A-Code aviation connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2).
Client softwareMVS or third-party software meeting with GigE Vision Protocol

Environment and compliance

Ingress protectionIP67 (under proper lens and lens cap installation and wiring)
TemperatureWorking temperature: –30 °C to 60 °C (–22 °F to 140 °F); Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F)
Humidity20% RH to 95% RH (no condensation)
CertificationCE, RoHS, KC

Computing

Operating system32/64-bit Windows 7/10, 64-bit Windows 11, 32/64-bit Linux

Electrical

Power supply9 VDC to 24 VDC, supports PoE
Power consumptionTyp. 1.6 W @ 24 VDC (fast heat balance not enabled and external device not be controlled)

Mechanical

Lens mountC-mount
Dimension42 mm × 42 mm × 43 mm (1.7" × 1.7" × 1.7")
WeightApprox. 120 g (0.3 lb.)
Shipping weight (estimated)0.27 kg

Engineering data

Field of view and resolution with the MV-CT2CG0050/G/NN/NN

Worked out from this camera's own sensor: the field of view and the size one pixel covers on the part, for common lenses and working distances.

Sensor area8.45 × 7.07 mm2/3" optical format
Lens image circle needed≥ Ø 11 mmC-mount
Pixel pitch3.45 µm2448 x 2048 px
Image data at max frame rate123 MB/sCalculated: 24.5 fps × 2448 × 2048 px at 8 bit · GigE carries 125 MB/s nominal
With a 16 mm lens at 500 mm264 × 221 mm0.108 mm per pixel
Dynamic range73.9 dB
SNR42.4 dB
Power consumption1.6 Wtyp. at 24 V DC
ShutterGlobal
Weight120 gapprox.
Field of view (width × height) and object pixel size by lens focal length and working distance
LensAt 300 mmAt 500 mmAt 1000 mm
8 mm317 × 265 mm0.129 mm per pixel528 × 442 mm0.216 mm per pixel1056 × 884 mm0.431 mm per pixel
12 mm211 × 177 mm0.086 mm per pixel352 × 295 mm0.144 mm per pixel704 × 589 mm0.288 mm per pixel
16 mm158 × 133 mm0.065 mm per pixel264 × 221 mm0.108 mm per pixel528 × 442 mm0.216 mm per pixel
25 mm101 × 84.8 mm0.041 mm per pixel169 × 141 mm0.069 mm per pixel338 × 283 mm0.138 mm per pixel
35 mm72.4 × 60.6 mm0.03 mm per pixel121 × 101 mm0.049 mm per pixel241 × 202 mm0.099 mm per pixel
50 mm50.7 × 42.4 mm0.021 mm per pixel84.5 × 70.7 mm0.035 mm per pixel169 × 141 mm0.069 mm per pixel

Thin-lens approximation: field of view ≈ sensor size × working distance ÷ focal length. Object pixel size = field-of-view width ÷ horizontal pixels; a feature should span about 3-4 pixels to be measured reliably.

Compatible parts

Fits with this part

Checked with the configurator's fit rules: lens mount, image circle, resolution and spectral band, and the camera's printed connector for cables.

Build the full system with this part

Lenses for this C-mount camera

Covers up to 11 mm diagonal; this camera's sensor is 11 mm

Covers up to 11 mm diagonal; this camera's sensor is 11 mm

Covers up to 11 mm diagonal; this camera's sensor is 11 mm

Covers up to 11 mm diagonal; this camera's sensor is 11 mm

Covers up to 11 mm diagonal; this camera's sensor is 11 mm

Covers up to 11 mm diagonal; this camera's sensor is 11 mm
