Hikrobot MV-CT1MG0032/G/NN/NN 3.2MP Area Scan Camera, 3rd Gen., GigE, Mono, PRO

Model MV-CT1MG0032/G/NN/NNHikrobot

Resolution2048 × 1536
SensorCMOS, global shutter
Lens mountC-mount
Mono / colourMono
Pixel size3.45 μm × 3.45 μm

$649.00

Ships in 2-3 weeks

0.27 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Hikrobot MV-CT1MG0032/G/NN/NN 3.2MP Area Scan Camera, 3rd Gen., GigE, Mono, PRO. The devices with PRO version and MAX version support waterproof connector. The devices with PRO version and MAX version adopt precision temperature control design for fast heat balance.

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our licensed P.E. engineers
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items; free return label in the US
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	MV-CT1MG0032/G/NN/NN
Brand	Hikrobot
Compatibility	GigE Vision V2.0, GenICam

Sensor and imaging

Sensor type	CMOS, global shutter
Sensor model	Stacked BSI
Pixel size	3.45 μm × 3.45 μm
Sensor size	1/1.8"
Resolution	2048 × 1536
Max. frame rate	39 fps @ 2048 × 1536 Mono 8; 77.5 fps @ 2048 × 1536 Mono 8 (lossless compression mode enabled)
Dynamic range	73.9 dB
SNR	42.4 dB
Gain	High full well capacity: 0 dB to 12.8 dB; High sensitivity: 0 dB to 24 dB
Exposure time	High full well capacity: 30 μs to 10 sec; High sensitivity: 5 μs to 10 sec
Exposure mode	Off/Once/Continuous exposure mode, supports Trigger Width and Trigger Controlled
Mono/color	Mono
Pixel format	Mono 8/10/10Packed/12/12Packed
Binning	Supports 1 × 1, 2 × 2, 4 × 4
Decimation	Supports 1 × 1, 2 × 2, 4 × 4
Reverse image	Supports horizontal and vertical reverse image output

Interfaces and I/O

Data interface	Gigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s)
Data interface type	8-pin M12 X-Code waterproof aviation connector
Control interface	Not support
Digital I/O	8-pin M8 A-Code aviation connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2).
Client software	MVS or third-party software meeting with GigE Vision Protocol

Environment and compliance

Ingress protection	IP67 (under proper lens and lens cap installation and wiring)
Temperature	Working temperature: –30 °C to 60 °C (–22 °F to 140 °F); Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F)
Humidity	20% RH to 95% RH (no condensation)
Certification	CE, RoHS, KC

Computing

Operating system	32/64-bit Windows 7/10, 64-bit Windows 11, 32/64-bit Linux

Electrical

Power supply	9 VDC to 24 VDC, supports PoE
Power consumption	Typ. 1.5 W @ 12 VDC (fast heat balance not enabled)

Mechanical

Lens mount	C-mount
Dimension	29 mm × 29 mm × 42 mm (1.1" × 1.1" × 1.7")
Weight	Approx. 124 g (0.3 lb.)
Shipping weight (estimated)	0.27 kg

Downloads

Features

The devices with PRO version and MAX version support waterproof connector.
The devices with PRO version and MAX version adopt precision temperature control design for fast heat balance.
The color devices with PRO version and MAX version support auto color correction based on multi-spectral fusion technology.
The device with MAX version integrates lens and light source, enabling lens focusing and light source control.
Adopts GigE interface and max. transmission distance of 100 meters without relay.
Compatible with GigE Vision V2.0 Protocol, GenlCam Standard, and third-party software based on the protocol and standard.

Complete the station

The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.

Build a system with this part Configure a system Ask an engineer
