Hikrobot MV-CS050-80GC 5MP Area Scan Camera, GigE, Color
Model MV-CS050-80GCHikrobot
- Resolution2448 × 2048
- SensorCMOS, global shutter
- Speed24 fps @ 2448 × 2048 Bayer BG 8
- Lens mountC-mount
- Mono / colourColor
- Pixel size3.45 μm × 3.45 μm
$819.00
Ships in 2-3 weeks
0.24 kg shipping weight
Not available in the United States. Available for delivery to other countries.
Hikrobot MV-CS050-80GC 5MP Area Scan Camera, GigE, Color. Adopts brand new design to reduce power consumption. Supports auto or manual adjustment for gain, exposure control, white balance, contrast ratio, Gamma correction, etc.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | MV-CS050-80GC |
|---|---|
| Brand | Hikrobot |
| Compatibility | GigE Vision V2.0, GenICam |
| EMVA quantum efficiency | 69.98 % |
| EMVA dark noise | 12.0e- @ 12 bit |
| EMVA saturation capacity | 15.4 ke- |
Sensor and imaging
| Sensor type | CMOS, global shutter |
|---|---|
| Sensor model | SS |
| Pixel size | 3.45 μm × 3.45 μm |
| Sensor size | 2/3" |
| Resolution | 2448 × 2048 |
| Max. frame rate | 24 fps @ 2448 × 2048 Bayer BG 8 |
| Dynamic range | 61.8 dB |
| SNR | 41.9 dB |
| Gain | 0 dB to 12 dB |
| Exposure time | 25 μs to 10 sec |
| Exposure mode | Off/Once/Continuous exposure mode |
| Pixel format | Mono 8; Bayer BG 8/10/10Packed/12/12Packed; YUV422Packed, YUV422_YUYV_Packed; RGB 8, BGR 8 |
| Binning | Supports 1 × 1, 2 × 2, 4 × 4 |
| Decimation | Supports 1 × 1, 2 × 2, 4 × 4 |
| Reverse image | Supports horizontal and vertical reverse image output |
| Mono/color | Color |
Interfaces and I/O
| Data interface | Gigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s) |
|---|---|
| Digital I/O | 6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2). |
| Client software | MVS or third-party software meeting with GigE Vision Protocol |
Environment and compliance
| Ingress protection | IP40 (under proper lens installation and wiring) |
|---|---|
| Temperature | Working temperature: –30 °C to 60 °C (–22 °F to 140 °F); Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F) |
| Humidity | 20% RH to 95% RH (no condensation) |
| Certification | CE, RoHS, KC |
Computing
| Operating system | 32/64-bit Windows 7/10, 64-bit Window 11, and 32/64-bit Linux |
|---|
Electrical
| Power supply | 9 VDC to 24 VDC, supports PoE |
|---|---|
| Power consumption | Typ. 1.3 W @ 12 VDC |
Mechanical
| Lens mount | C-mount |
|---|---|
| Dimension | 29 mm × 29 mm × 42 mm (1.1" × 1.1" × 1.7") |
| Weight | Approx. 102 g (0.2 lb.) |
| Shipping weight (estimated) | 0.24 kg |
