Long-travel manual X stages, MISUMI type, 40 x 90 / 40 x 140 mm (LS-X4090M)
Model LS-X4090M
- MaterialAluminum alloy, anodized
- Travel70 mm
- TypeManual slide stages
- Size40 x 90 mm
$159.00
In stock - ships the same business day (3 available, order by 2 PM ET)
0.55 kg shipping weight
Volume pricing, Net 30 or a formal quote?
Long-travel manual X stages, MISUMI type, 40 x 90 / 40 x 140 mm. Long-distance horizontal X-axis stages of the MISUMI pattern, 40 x 90 and 40 x 140 mm. At a glance: travel 70 mm; size 40 x 90 mm.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-X4090M |
|---|---|
| Drive | Gear rack, manual |
| Min. scale | 0.1 mm |
| Axis | X |
| Movement | X axis |
Mechanical
| Size | 40 x 90 mm |
|---|---|
| Travel | 70 mm |
| Overall length | 90 mm |
| Material | Aluminum alloy, anodized |
| Weight | 0.32 kg |
| Plate size | 40 x 90 mm |
| Shipping weight (estimated) | 0.55 kg |
