  • LS-VCM71M-48S-AL dimensions (mm)

Telecentric lenses

Bi-telecentric lens for 39mm cameras, 0.813x, WD 138 mm, F or Other-mount (LS-VCM71M-48S-AL)

Model LS-VCM71M-48S-AL

  • Magnification0.813x
  • MountF-mount
  • SensorAPS-H
  • Working distance138±3
  • Field of view48
$1,949.00

In stock - ships the same business day (3 available, order by 2 PM ET)

1.22 kg shipping weight

Volume pricing, Net 30 or a formal quote?

Bi-telecentric lens series for sensors up to 71M (39 mm dia.), F-Mount/Other. Models are named by object field of view (dia. mm); each lists magnification, working distance, F/#, MTF30, depth of field, distortion <0.1% and telecentricity <0.1°.

  • Same-day shipping on stock itemsTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our licensed P.E. engineers
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items; free return label in the US
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-VCM71M-48S-AL

Optics

Distortion (% max)<0.1
Telecentricity (deg max)<0.1
Magnification (x)0.813
Object field of view (dia. mm)48
Working distance (mm)138±3
Best Aperture (F/#)22.9
MTF30 (lp/mm)>35
Depth of field (mm)±1.3@F22.9
Field of view with CHR 70M (31.0x21.7 sensor) (mm x mm)38.1x26.7
Compatible telecentric led lightingLS-VCL-48-XW-Y

Sensor and imaging

Max sensor size (dia. mm)39(71M)

Interfaces and I/O

Length of I/O (mm)375±3

Mechanical

MountF-Mount/Other
Length (mm)190.7
Weight (kg)0.8
