Camera stands
Top-view camera module, 350 mm (LS-STD60350-XS)
Model LS-STD60350-XS
- TypeTop view module
- MaterialAluminum alloy, anodized
- Travel330
- Height350 mm
$159.00
In stock - ships the same business day (3 available, order by 2 PM ET)
4.3 kg shipping weight
Volume pricing, Net 30 or a formal quote?
Top-view camera module, 350 mm. Side-view, guide, upward-view and downward-view camera modules for inspection stations, with their spare parts. At a glance: travel 330; height 350 mm; plate size 60 x 90 mm.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-STD60350-XS |
|---|---|
| Drive | Gear rack, manual |
| Min. scale | 0.1 mm |
| Movement | YZ axes |
| Type | Top view module |
Mechanical
| Height | 350 mm |
|---|---|
| Plate size | 60 x 90 mm |
| Travel | 330 |
| Material | Aluminum alloy, anodized |
| Weight | 3 kg |
| Bottom base size | 60 x 90 mm |
| Shipping weight (estimated) | 4.30 kg |
