Side-view camera module, 300 mm (LS-STD60300)
Model LS-STD60300
- TypeSide view module
- MaterialAluminum alloy, anodized
- Travel280
- Height300 mm
$159.00
In stock - ships the same business day (2 available, order by 2 PM ET)
2.9 kg shipping weight
Volume pricing, Net 30 or a formal quote?
Side-view camera module, 300 mm. Side-view, guide, upward-view and downward-view camera modules for inspection stations, with their spare parts. At a glance: travel 280; height 300 mm; plate size 60 x 200 mm.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-STD60300 |
|---|---|
| Drive | Gear rack, manual |
| Min. scale | 0.1 mm |
| Movement | XZ axes |
| Type | Side view module |
Mechanical
| Height | 300 mm |
|---|---|
| Plate size | 60 x 200 mm |
| Travel | 280 |
| Material | Aluminum alloy, anodized |
| Weight | 2 kg |
| Bottom base size | 60 x 200 mm |
| Shipping weight (estimated) | 2.90 kg |
