  • LS-SPC-0157 dimensions (mm)

Special lights

Short wavelength infrared light, Ø59.2 mm (LS-SPC-0157)

Model LS-SPC-0157

  • Voltage700mA
  • Power2.2W
  • ColorSWIR
  • LED colourSWIR(short-wave infrared)
$549.00

Ships in 2-3 weeks

0.5 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

Short wavelength infrared light, Ø59.2 mm (LS-SPC-0157)LS-SPC-0157

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

Shortwave infrared, which is more penetrating, seven wavelengths available. 1050nm/ 1200nm/1300nm/1450nm/1550nm/1600nm/1650nm. Matched with SWIR camera.

  • Same-day shipping on stock itemsTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-SPC-0157
NoteUV & IR light can be customized as required.

Interfaces and I/O

Cable polarity1: NC, 2: +, 3: -
Cable (mm)500 (drawing)

Light

ColorSWIR
LED colourSWIR(short-wave infrared)
Emitting port dia. (mm)6.2

Electrical

Voltage/current700mA
Power2.2W
Supply voltage (derived)24 V DC, derived: every other LS-SPC-S01 model is rated 24 V

Mechanical

DimensionOuter dia. 59.2mm,Inner dia. 8mm,Height 22mm
Mounting holes2-M3 depth 5
Shipping weight0.50 kg

Photo shows the visible-light version of this light; this model emits short-wave infrared light - see the specifications.
