Line scan lights
Short wavelength infrared light, 500 x 53 x 121.5 mm (LS-LSC-0693)
Model LS-LSC-0693
- Emitting area484 x 24 mm
- SizeL500xW53xH121.5(mm)
- Voltage24V
- Power108W
$1,549.00
Ships in 2-3 weeks
2.05 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
Shortwave infrared, which is more penetrating, seven wavelengths available. 1050nm/ 1200nm/1300nm/1450nm/1550nm/1600nm/1650nm. Matched with SWIR camera.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-LSC-0693 |
|---|---|
| Note | UV & IR light can be customized as required. |
Interfaces and I/O
| Cable polarity | 1: +, 2: -, 3: FAN+, 4: FAN- |
|---|---|
| Cable (mm) | 3000 (drawing) |
Light
| Color | SWIR |
|---|---|
| LED colour | SWIR |
| Emitting surface (mm) | 484 x 24 |
Electrical
| Voltage/current | 24V |
|---|---|
| Power | 108W |
| Input voltage | DC 24V (max) |
Mechanical
| Dimension | L500xW53xH121.5(mm) |
|---|---|
| Mounting holes | 2×4-M5 depth 6 |
| Shipping weight | 2.05 kg |
Photo shows the visible-light version of this light; this model emits short-wave infrared light - see the specifications.
