Representative photo of this series
Special lights
High power strobe light, 94 x 70 x 70 mm (LS-SPC-0130)
Model LS-SPC-0130
- SizeL94xW70xH70(mm)
- Voltage48V
- TypeStrobe
- Current27A/32.4A
$759.00
Ships in 2-3 weeks
0.55 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
The brightness of illumination can improve 5-14 times by using the special power controller to achieve a high-power strobe illumination. By microsecond exposure, the maximum brightness can up to 5 million LX, so that the imaging contrast is obvious.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-SPC-0130 |
|---|---|
| Note | UV & IR light can be customized as required. |
Interfaces and I/O
| Cable polarity | 1: +, 2: NC, 3: - |
|---|---|
| Cable (mm) | 500 (drawing) |
Light
| LED colour | R(red)/W(white) |
|---|
Electrical
| Voltage | 48V |
|---|---|
| Current | 27A/32.4A |
Mechanical
| Dimension | L94xW70xH70(mm) |
|---|---|
| Mounting holes | 4-M3 depth 4.5 |
| Shipping weight | 0.55 kg |
