Representative photo of this series
Special lights
High power strobe light, Ø91 mm (LS-SPC-0126)
Model LS-SPC-0126
- Voltage48V
- TypeStrobe
- Current12A/12A
- LED colourR(red)/W(white)
$759.00
In stock - ships the same business day (4 available, order by 2 PM ET)
0.5 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
The brightness of illumination can improve 5-14 times by using the special power controller to achieve a high-power strobe illumination. By microsecond exposure, the maximum brightness can up to 5 million LX, so that the imaging contrast is obvious.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-SPC-0126 |
|---|---|
| Note | UV & IR light can be customized as required. |
Interfaces and I/O
| Cable polarity | 1: +, 2: NC, 3: - |
|---|---|
| Cable (mm) | 500 (drawing) |
Light
| LED colour | R(red)/W(white) |
|---|
Electrical
| Voltage | 48V |
|---|---|
| Current | 12A/12A |
Mechanical
| Dimension | Outer dia. 91mm,Inner dia. 41mm,Height 25.5mm |
|---|---|
| Mounting holes | 4-M4 depth 5, evenly spaced |
| Shipping weight | 0.50 kg |
