35 mm, 100 MP, F-mount Line Scan Lens (LS-SLS3528F-100M)
Model LS-SLS3528F-100M
- Focal length35mm
- MountF-mount
- SensorLarge format
- Working distance100 mm to infinity
- ApertureF2.8~16 Manual iris
- Resolution100Megapixel ( Pixel size 3.1μm )
$2,319.00
In stock - ships the same business day (5 available, order by 2 PM ET)
0.94 kg shipping weight
Volume pricing, Net 30 or a formal quote?
35 mm, 100 MP, F-mount Line Scan Lens. 100 megapixel (3.1 µm) 35 mm F2.8 line scan lens for full-size dia. 46 mm sensors, TV distortion -0.15%, magnification 0.035x-0.31x, F or V mount. At a glance: working distance 100 mm to infinity; focal length 35mm; format dia. 46mm ( Full size ); resolution 100Megapixel ( Pixel size 3.1μm ); aperture F2.8~16 Manual iris.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-SLS3528F-100M |
|---|---|
| Format | dia. 46mm ( Full size ) |
| FOV | 64 x 54.5 x 37.7 ( Sensor 37.9 x 25.2mm ) |
| CRA | 20.1° |
| Notes | Max TTL122.5mm; B.F.L 20.2mm; 14G; >85% |
Optics
| Focal length | 35mm |
|---|---|
| Aperture | F2.8~16 Manual iris |
| Distortion (TV) | -0.15% |
| Relative illumination | 38.7% |
| M.O.D. | 100mm |
| Max image circle | dia. 46 mm (3.1 um pixel) |
| Working distance | 100 mm to infinity |
Sensor and imaging
| Resolution | 100Megapixel ( Pixel size 3.1μm ) |
|---|---|
| Sensor class | 3.1 um pixel, 100 MP |
Environment and compliance
| Operating temperature | -10~50°C |
|---|
Mechanical
| Filter size | M52 x 0.75 |
|---|---|
| Size | dia. 55.5 x 86.2mm |
| Mount | F |
| Mount options | M42, M58, M72, F |
| Shipping weight (estimated) | 0.94 kg |
