Ring light
  • Ring light
  • LS-RNG-0884 dimensions (mm)

Ring lights

62.4 mm UV light, LS-RNG-S44 series (LS-RNG-0884)

Model LS-RNG-0884

  • Power4.1 W
  • TypeDiffused
  • Angle30°
  • Voltage24 V
$269.00

Ships in 2-3 weeks

0.5 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

62.4 mm UV light, LS-RNG-S44 series (LS-RNG-0884)LS-RNG-0884

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

Uses imported high-output UV LEDs; uses differences in scattering and spectral reflectance for a variety of measurements.

  • Same-day shipping on stock itemsTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-RNG-0884
Service lifeAt 25 °C ambient: red works continuously for 60000 hours at 50% illumination, white 30000 hours at 50% illumination (decrement at 50%)
Optional accessoriesExtension cable

Interfaces and I/O

Cable length (mm)500

Light

Luminous dimension (mm)62.4
Illumination angle (schematic)30°
Diffuserwith diffuse plate
Wavelength UV365 nm

Environment and compliance

Storage temperature-20-60 °C
Operating temperature0-40 °C
Humidity20-85 %RH (non-condensing)

Electrical

ControllerLS-CTL-S69, LS-CTL-S28, LS-CTL-S125, LS-CTL-S32 series (match the power of the light source)
Power (W)4.1
Recommended controllerLS-CTL-S69, LS-CTL-S28, LS-CTL-S125
Supply voltage (derived)24 V DC, derived from the 24 V output of its recommended controllers LS-CTL-S69, LS-CTL-S28

Mechanical

Overall size (mm)OD74 x ID40 x H20
Shipping weight0.50 kg

Photo shows the visible-light version of this light; this model emits 365 nm ultraviolet light - see the specifications.
