Representative photo of this series
Machine vision lenses
Large format lens, 60 mm, F-Mount (LS-MF6016A)
Model LS-MF6016A
- Focal length60 mm
- Magnification0.01X-0.4X
- MountF-mount
- SensorLarge format
- Working distance384.9 mm
- ApertureF4.0-32
$839.00
In stock - ships the same business day (5 available, order by 2 PM ET)
0.38 kg shipping weight
Volume pricing, Net 30 or a formal quote?
Large format lenses with max image circle up to 43 mm, supporting 29MP sensors and suitable for 4K line scan cameras with 5 µ/7 µ pixels; better optical performance than SLR lenses, with standard EFL and magnification options, applied to printing and packaging inspection.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-MF6016A |
|---|---|
| EFL | 60mm |
| F/NO | 4.0-32 |
| Conjugate distance | 496.32 |
| Flange distance | 46.5 |
Optics
| Magnification range | 0.01X-0.4X |
|---|---|
| Distortion | <0.01% |
| Standard magnification | 0.167X |
| Image size (dia.) | dia. 64 |
| Optical distortion | 0.19% |
| Working distance | 384.9 |
| Focal length (mm) | 60 |
| Aperture | F4.0-32 |
Sensor and imaging
| Sensor format | dia. 64 mm image circle |
|---|
Mechanical
| Mount | F-Mount |
|---|---|
| Filter size | M65×P0.75 |
| Shipping weight | 0.38 kg |
