M12 board lenses
2.8 mm, 1/2.7", 4 MP, M12-mount Starlight Low-Light Lens (LS-MBL-0196)
Model LS-MBL-0196
- Focal length2.8 mm
- MountM12
- Sensor1/2.7"
- ApertureF1.4 Fixed iris
- Resolution4.0 Megapixel
$59.00
Ships in 2-3 weeks
0.11 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
2.8 mm, 1/2.7", 4 MP, M12-mount Starlight Low-Light Lens. 2.8 mm F1.4 starlight-level 4 megapixel M12 lens with aspherical elements, a wide FOV for short-distance views and day/night IR correction; the 1/2.7" format covers 1/2.7" and 1/3" cameras. At a glance: focal length 2.8 mm; format 1/2.7"; resolution 4.0 Megapixel; aperture F1.4 Fixed iris; mount M12 x 0.5.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-MBL-0196 |
|---|---|
| IR correction | IR corrected (day/night) |
| Format | 1/2.7" |
| Angle of view (1/2.7", DxHxV) | 135 x 114 x 62 deg |
| Lens structure (aspherical) | 4G4P |
Optics
| Focal length | 2.8 mm |
|---|---|
| Aperture | F1.4 Fixed iris |
| M.O.D. | 0.1 m |
| Total track length (TTL) | 23.5 mm |
Sensor and imaging
| Resolution | 4.0 Megapixel |
|---|
Mechanical
| Size | dia. 39 x 65.5 |
|---|---|
| Mount | M12 x 0.5 |
| Weight | 10 g |
| Shipping weight (estimated) | 0.11 kg |
