Line scan lenses
16K 3.5µ line scan lens, 116 mm, V-Mount, working distance 237.4 mm (LS-LS1667A)
Model LS-LS1667A
- Focal length116mm
- Magnification0.05X-1X
- MountV-mount
- SensorLarge format
- Working distance237.4 mm
- ApertureF3.8-16
$2,369.00
In stock - ships the same business day (4 available, order by 2 PM ET)
0.94 kg shipping weight
Volume pricing, Net 30 or a formal quote?
Line scan lenses specially designed for 16K 3.5 µm super-high-resolution line scan cameras; real lens resolution up to 160 lp/mm, max image circle up to 66 mm, compatible with 12K 5 µ cameras, optical distortion <1 pixel, big aperture F3.8.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-LS1667A |
|---|---|
| Line scan format | 16K 3.5µ |
| EFL | 116mm |
| F/NO | 3.8-16 |
| Conjugate distance | 453.5 |
| Flange distance | 170.2 |
Optics
| Focal length | 116mm |
|---|---|
| Magnification range | 0.05X-1X |
| Distortion | <0.005% |
| Standard magnification | 0.67X |
| Image size (dia.) | dia. 66 |
| Optical distortion | 0.1% |
| Working distance | 237.4 |
| Focal length (mm) | 116 |
| Aperture | F3.8-16 |
Sensor and imaging
| Central resolution | 200lp/mm |
|---|---|
| Sensor format | dia. 66 mm image circle |
Mechanical
| Mount | V-Mount |
|---|---|
| Shipping weight | 0.94 kg |
