Machine vision lenses
12-36 mm zoom lens, 2/3", 3 MP, C-mount (LS-FFL-1702)
Model LS-FFL-1702
- Focal length12-36 mm
- MountC-mount
- Sensor2/3"
- Working distanceW: 0.15m- ∞ T: 0.45m- ∞
- ApertureManual
- Resolution3MP
$1,280.00
Ships in 3-4 weeks
1.0 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
12-36 mm zoom lens for machine-vision cameras. Focal length 12-36 mm; covers sensors up to 2/3"; resolves 3 MP; C-mount.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-FFL-1702 |
|---|---|
| Zoom | Manual |
Optics
| Focal length | 12-36 mm |
|---|---|
| Working distance | W: 0.15m- ∞ T: 0.45m- ∞ |
| Field of view | W:50.8° /41.3° /31.2° T: 17.0° /13.8° /10.4° |
| Distortion | W: -3.43%@y=5.5 T: 2.30%@y=5.5 |
| Aperture | Manual |
| Focus | Manual |
| Filter thread | M35.5×0.5 |
Sensor and imaging
| Sensor format | 2/3" |
|---|---|
| Resolution | 3MP |
Light
| Wavelength range | 420-1000 nm |
|---|
Environment and compliance
| Operating temperature | -20~+60° C |
|---|
Mechanical
| Mount | C-Mount |
|---|---|
| Flange back length | 17.526 mm |
| Dimensions | Φ36 x 59 |
| Weight | 105.25g |
