50mm, F1.4, 1", 900-1700nm, C-mount, SWIR lens (LS-KF5014M-3MP-NIR)
  • 50mm, F1.4, 1", 900-1700nm, C-mount, SWIR lens (LS-KF5014M-3MP-NIR)
  • LS-KF5014M-3MP-NIR dimensions (mm)

Machine vision lenses

50mm, F1.4, 1", 900-1700nm, C-mount, SWIR lens (LS-FFL-1544)

Model LS-FFL-1544

  • Focal length50mm
  • MountC-mount
  • Sensor1"
  • ApertureF1.4
$489.00

In stock - ships the same business day (2 available, order by 2 PM ET)

0.39 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

50mm, F1.4, 1", 900-1700nm, C-mount, SWIR lens (LS-FFL-1544)LS-FFL-1544

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

50mm, F1.4, 1", 900-1700nm, C-mount, SWIR lens. Maximum sensor format 1'' Large-aperture design for high light throughput

  • Same-day shipping on stock itemsTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our licensed P.E. engineers
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items; free return label in the US
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-FFL-1544
Minimum object distance0.5m

Optics

Focal length50mm
F-numberF1.4
Image size1”
Distortion0.6%
Iris controlManual
Focus controlManual
Filter threadM40.5×0.5

Interfaces and I/O

Connector typeC-Mount

Environment and compliance

Temperature-10 ~ 50°C
CertificationRoHS2.0

Mechanical

Flange back length17.526mm
DimensionΦ47.2×55.58mm
Weight210g
Shipping weight (estimated)0.39 kg

Other models in the SWIR Lens Series (LS-FFL-S149) series

See all 9 models
ModelSize / key dataPriceAvailabilityLink
LS-FFL-1540 12mm · C-mount $369.00 3 in stock View
LS-FFL-1541 16mm · C-mount $389.00 5 in stock View
LS-FFL-1542 25mm · C-mount $449.00 3 in stock View
LS-FFL-1543 35mm · C-mount $449.00 5 in stock View
LS-FFL-1537 25mm · M42 $449.00 4 in stock View
LS-FFL-1538 40mm · M42 $489.00 3 in stock View
LS-FFL-1539 50mm · M42 $489.00 4 in stock View
LS-FFL-1545 100mm · C-mount $779.00 4 in stock View
