Representative photo of this series
Machine vision lenses
Industrial lens, 1/1.8" 5MP FA lens, 75 mm, C-mount (LS-FFL-0416)
Model LS-FFL-0416
- Focal length75 mm
- MountC-mount
- Sensor1/1.8"
- Aperture2.8
- Resolution5
- Field of view39.66 x 29.72*
$309.00
In stock - ships the same business day (5 available, order by 2 PM ET)
0.38 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
Industrial lens, 1/1.8" 5MP FA lens with mount C Mount, max image surface size 1/1.8", focal length 75, aperture 2.8, fov @ wd 200 39.66 x 29.72*.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-FFL-0416 |
|---|---|
| Min distance | 0.5M |
Optics
| Focal length (mm) | 75 |
|---|---|
| Aperture | 2.8 |
| TV distortion | <0.05% |
| Filter thread | M25.5 x P0.5 |
| Field of view | 39.66 x 29.72* |
Sensor and imaging
| FOV @ WD 200 (H x V), 1/1.8" sensor | 39.66 x 29.72* |
|---|---|
| FOV @ WD 200 (H x V), 1/2.5" sensor | 32.02 x 24.04* |
| FOV @ WD 200 (H x V), 1/3" sensor | 26.61 x 19.96* |
| Sensor format | 1/1.8" |
| Resolution (MP) | 5 |
Interfaces and I/O
| Interface | C Mount |
|---|
Mechanical
| Mount | C Mount |
|---|---|
| Max image surface size | 1/1.8" |
| Shipping weight | 0.38 kg |
Other models in the Industrial lens, 1/1.8" 5MP FA lens (LS-FFL-S76) series
See all 9 models| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-FFL-0410 | 8 mm, 1/1.8", C-mount | $169.00 | 4 in stock | View |
| LS-FFL-0411 | 12 mm, 1/1.8", C-mount | $179.00 | 5 in stock | View |
| LS-FFL-0408 | 4 mm, 1/1.8", C-mount | $209.00 | 5 in stock | View |
| LS-FFL-0409 | 6 mm, 1/1.8", C-mount | $209.00 | 4 in stock | View |
| LS-FFL-0412 | 16 mm, 1/1.8", C-mount | $239.00 | 5 in stock | View |
| LS-FFL-0415 | 50 mm, 1/1.8", C-mount | $249.00 | 3 in stock | View |
| LS-FFL-0413 | 25 mm, 1/1.8", C-mount | $289.00 | 5 in stock | View |
| LS-FFL-0414 | 35 mm, 1/1.8", C-mount | $319.00 | 2 in stock | View |
