Representative photo of this series
Machine vision lenses
Fixed lens for FA, 4/3" 20MP, 35 mm, C-Mount (LS-FA3520A)
Model LS-FA3520A
- Focal length35 mm
- MountC-mount
- Sensor4/3"
- ApertureF2.8-22
- Resolution20MP
- Field of view27.9° x 20.9°
$479.00
In stock - ships the same business day (3 available, order by 2 PM ET)
0.38 kg shipping weight
Volume pricing, Net 30 or a formal quote?
Industrial FA lenses supporting 4/3" sensors and compatible with 1.1" and 2/3" sensors, for 20MP area array cameras, with high relative illuminance, large aperture, compact structure and high contrast.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-FA3520A |
|---|---|
| F/NO | 2.8-22 |
| EFL | 35mm |
| MOD | 0.2m |
Optics
| Distortion | <0.1% |
|---|---|
| Image size | 4/3" |
| Image size (dia.) | 4/3" |
| Field of view angle 4/3" | 27.9° x 20.9° |
| Field of view angle 1" | 20.6° x 15.45° |
| Field of view angle 2/3" | 14.3° x 10.7° |
| Distortion (TV) 4/3" | <0.04% |
| Focal length (mm) | 35 |
| Aperture | F2.8-22 |
Sensor and imaging
| Resolution | 20MP |
|---|---|
| Sensor format | 4/3" |
Mechanical
| Mount | C-Mount |
|---|---|
| Filter size | M35.5×P0.5 |
| Shipping weight | 0.38 kg |
