Representative photo of this series
Machine vision lenses
Fixed lens for FA, 4/3" 20MP, 25 mm, C-Mount (LS-FA2520A)
Model LS-FA2520A
- Focal length25 mm
- MountC-mount
- Sensor4/3"
- ApertureF2.8-22
- Resolution20MP
- Field of view37.5° x 28.5°
$469.00
In stock - ships the same business day (2 available, order by 2 PM ET)
0.38 kg shipping weight
Volume pricing, Net 30 or a formal quote?
Industrial FA lenses supporting 4/3" sensors and compatible with 1.1" and 2/3" sensors, for 20MP area array cameras, with high relative illuminance, large aperture, compact structure and high contrast.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-FA2520A |
|---|---|
| F/NO | 2.8-22 |
| EFL | 25mm |
| MOD | 0.1m |
Optics
| Distortion | <0.1% |
|---|---|
| Image size | 4/3" |
| Image size (dia.) | 4/3" |
| Field of view angle 4/3" | 37.5° x 28.5° |
| Field of view angle 1" | 27.6° x 20.9° |
| Field of view angle 2/3" | 19.2° x 14.5° |
| Distortion (TV) 4/3" | <0.3% |
| Focal length (mm) | 25 |
| Aperture | F2.8-22 |
Sensor and imaging
| Resolution | 20MP |
|---|---|
| Sensor format | 4/3" |
Mechanical
| Mount | C-Mount |
|---|---|
| Filter size | M35.5×P0.5 |
| Shipping weight | 0.38 kg |
Other models in the Fixed lens for FA, 4/3" 20MP series
See all 5 models| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-FA1220A | 12 mm, 4/3", C-Mount | $449.00 | 4 in stock | View |
| LS-FA1620A | 16 mm, 4/3", C-Mount | $459.00 | 4 in stock | View |
| LS-FA3520A | 35 mm, 4/3", C-Mount | $479.00 | 3 in stock | View |
| LS-FA5020A | 50 mm, 4/3", C-Mount | $499.00 | 4 in stock | View |
