Machine vision lenses
Fixed lens for FA, 1.1" 20MP, 6 mm, C-Mount (LS-FA0615A)
Model LS-FA0615A
- Focal length6 mm
- MountC-mount
- Sensor1.1"
- ApertureF1.8-16
- Resolution20MP
- Field of view104.9° x 86.2°
$439.00
In stock - ships the same business day (3 available, order by 2 PM ET)
0.38 kg shipping weight
Volume pricing, Net 30 or a formal quote?
Ultra-high imaging quality 1.1" FA lenses supporting 20MP area scan cameras, with high relative illumination, big aperture, distortion <0.1%, focus from 0.1 m to infinity; compatible with 1" and 2/3" sensors.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-FA0615A |
|---|---|
| F/NO | 2.8-22 |
| EFL | 6mm |
| MOD | 0.1m |
Optics
| Distortion | <0.1% |
|---|---|
| Image size | 1.1" |
| Image size (dia.) | 1.1" |
| Field of view angle 1.1" | 104.9° x 86.2° |
| Field of view angle 1" | 95.4° x 78.4° |
| Field of view angle 2/3" | 73.3° x 57.5° |
| Distortion (TV) 1.1" | <2.5% |
| Focal length (mm) | 6 |
| Aperture | F1.8-16 |
Sensor and imaging
| Resolution | 20MP |
|---|---|
| Sensor format | 1.1" |
Mechanical
| Mount | C-Mount |
|---|---|
| Shipping weight | 0.38 kg |
