Representative photo of this series

Light controllers

Digital control box, 4 ch, 80 W (LS-CTL-0065)

Model LS-CTL-0065

Channels4
Output24V
InputDC 24V
Total output3.34A
ControlRS232

$469.00

Ships in 2-3 weeks

0.35 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Digital control box, high cost-effective: constant on and strobe mode optional, 0-255ms strobe lighting time can be set, 10us short delay time, 256-level luminance adjustable.

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	LS-CTL-0065
Working mode	Constant on / Trigger / Strobe
Constant on / off switch	H mode set by encoder knob: H1 constant on, H0 constant off
Product	Digital controller
Remark	Communication, external trigger, luminance level display and etc.
Control	encoder knob + digital display / RS232

Interfaces and I/O

Communication	RS232

Light

Luminance adjustment method	manual adjust by knob, PC remote adjusting
Luminance adjustment mode	PWM adjust
Luminance adjustment level	256 level

Environment and compliance

Operating environment	humidity 20%-85%RH (frost free), 0-50 C
Storage environment	humidity 20%-85%RH (frost free), 0-60 C

Computing

Memory function	data saved automatically when power off

Electrical

Input voltage	DC 24V
Total output current	3.34A
Baud rate	9600 bps
Trigger delay time	<=10us
External trigger voltage	5-24V
Input frequency range	50/60Hz
Output voltage	24V
External trigger frequency	Determined by the external trigger signal; with 50% duty ratio the max. effective trigger frequency is 4KHz
External trigger delay time	10us
Extenal trigger voltage	5-24V
Channels	4
One way max. output power	80W
Total output power	80W
External trigger support	Y

Mechanical

Mounting	DIN guide rail mounting base
Shipping weight	0.35 kg

Downloads

Datasheet (PDF)LS-CTL-0065 · 1.3 MB

Features

High cost-effective
Constant on and strobe mode optional
0-255ms strobe lighting time can be set
10us short delay time, 256-level luminance adjustable
Encoder knob: H1 constant on / H0 constant off; press knob for P mode (P1 exit strobe, P0 enter strobe)
Overcurrent protection: display shows Er03, cleared by restart or reset command
Support RS232 /LAN communication
High trigger frequency, short response time 10us
2-12 channels for optional
Power off saving function
Have a 12V 500mA output to supply camera

Complete the station

The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.

Build a system with this part Configure a system Ask an engineer

Other models in the Digital control box (LS-CTL-S09) series

See all 14 models

Model	Size / key data	Price	Availability	Link
LS-CTL-0061	2 ch, 60 W	$359.00	Ships in 2-3 weeks	View
LS-CTL-0062	2 ch, 60 W	$359.00	Ships in 2-3 weeks	View
LS-CTL-0063	4 ch, 60 W	$459.00	Ships in 2-3 weeks	View
LS-CTL-0064	4 ch, 60 W	$459.00	Ships in 2-3 weeks	View
LS-CTL-0066	4 ch, 120 W	$489.00	Ships in 2-3 weeks	View
LS-CTL-0067	4 ch, 120 W	$489.00	Ships in 2-3 weeks	View
LS-CTL-0070	4 ch, 200 W	$539.00	Ships in 2-3 weeks	View
LS-CTL-0071	4 ch, 200 W	$539.00	Ships in 2-3 weeks	View
LS-CTL-0068	8 ch, 120 W	$669.00	Ships in 2-3 weeks	View
LS-CTL-0069	8 ch, 120 W	$669.00	Ships in 2-3 weeks	View
LS-CTL-0072	8 ch, 200 W	$709.00	Ships in 2-3 weeks	View
LS-CTL-0073	8 ch, 200 W	$709.00	Ships in 2-3 weeks	View
LS-CTL-0074	12 ch, 200 W	$889.00	Ships in 2-3 weeks	View
