Area scan cameras

10 GigE area scan camera, 104 MP, 10GigE, Color/Mono (LS-CMR-0325)

Model LS-CMR-0325

Resolution11276×9200
SensorCMOS
Speed11.6
Lens mountM58
Pixel size3.2μm

$10,959.00

Quote

Quoted price: add to quote for lead time and volume pricing.

Ships in 2-3 weeks

0.8 kg shipping weight

Quantity

Collect parts in your quote list; we reply with price, lead time and volume pricing.

10 Gigabit network area scan cameras from 0.5MP to 65MP (selection table up to 100MP) for high frame rate and high resolution requirements. Widely used in PCB, screen detection, lithium battery and railway.

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	LS-CMR-0325
Programming language pack	C/C++/C#/VB6/VB.NET/Delphi/BCB/Python/Java
Driver	Directshow component Halcon special component Labview special driver OCX component TWAIN component
Other functions	Support any size ROI custom resolution, contrast and gamma adjustment, saturation adjustment, white balance correction, black level correction, custom dead point coordinate correction, ISP image processing acceleration, 3D noise reduction, custom LUT table, frame rate adjustment, custom camera name, etc.
Acquisition mode	Continuous/soft trigger/hard trigger
User-defined data area	2K Bytes
Vision standard	GigE Vision V1.2, GenICam
Filter	Black and white cameras: double-sided AR antireflection film as standard; color cameras: 650nm infrared cut filter as standard
Sensitivity	-83.5dB (CRA dependent)
Frame buffer	1GB

Sensor and imaging

Pixel	100MP
Sensor type	CMOS
Shutter method	Global
Maximum resolution	11276×9200
Pixel size	3.2μm
Frame rate (FPS)	11.6
Minimum exposure	0.001ms
Sensor model	OEM
Resolution @ frame rate	11276x9200@11.6FPS
Pixel size (detail)	3.2μm×3.2μm
Pixel bit depth	12bit
Maximum gain (multiple)	4
Exposure time range (ms)	0.001~60s
Sensor format	36.1×29.4mm

Interfaces and I/O

GPIO	2 inputs and 2 outputs, 1 configurable input and output, support trigger and flash sync mode
Data interface	10G copper cable 10GBase-T, compatible with 100M/1G/2.5G/5G
Video output format	Color: Bayer 8/12bit; Mono: Mono 8/12bit

Light

Colour	Color/Mono
Mono / colour	Color/Mono

Environment and compliance

Working temperature @ humidity	0~50℃ @ 20%~80% (no condensation)
Storage temperature @ humidity	-30~60℃ @ 20%~95% (no condensation)

Computing

Operating system	WIINXP, WIN7/8/10 32@64 bit system, Linux and ARM Linux driver, Android platform driver, MAC OS system

Electrical

Power	<12W
Power supply	12~24V (±10%)
Voltage	12~24V (±10%)

Mechanical

Target size	36.1×29.4mm
Lens mount	M58
Dimensions	64×64×52.7mm (without lens mount and rear shell interface)
Weight	<500g

Downloads

Datasheet (PDF)LS-CMR-0325 · 1.8 MB

Features

Reserved fan interface to control camera temperature
0.5MP to 100MP pixels with a maximum frame rate of 1594FPS
Standard 10 Gigabit network interface; stable communication over Cat6 (super six) network cable
Cost greatly reduced compared with CameraLink interface plus capture card
Transmission distance up to 100 meters, backward compatible with Gigabit Ethernet
Effective bandwidth 1200MByte, 10 times Gigabit network, greatly reducing image transmission time and delay
Supports GigE Vision and GenICam, same SDK as the Gigabit network camera, shortening development cycle
Using standard 10 Gigabit network interface design.
The maximum transmission distance up to 100 meters , compatible with gigabit network.
Effective bandwidth of 1200MByte , which is 10 times that of Gigabit network.
Supports PC Linux system and ARM Linux system.
Compatible with Vision protocol and other brand vision software.

Applications

PCB
Screen detection
Lithium battery
Railway

Complete the station

The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.

Build a system with this part Configure a system Ask an engineer
