43 x 35 mm Collimated LED Backlight (LS-BCP-43X35)
Model LS-BCP-43X35
- ColourRed, Green, Blue, White
- Emitting area43x35 mm
- Size57x49x19 mm
- Voltage24 V
- Power2.5 W
$99.00
In stock - ships the same business day (5 available, order by 2 PM ET)
0.25 kg shipping weight
Volume pricing, Net 30 or a formal quote?
43 x 35 mm Collimated LED Backlight. Collimated bottom-lit backlight (LED array + diffuser) that sharpens product edges and raises contrast; same footprints as the BC series, 19 mm thick.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-BCP-43X35 |
|---|---|
| Construction (setup diagram) | LED / housing / diffuser plate |
Interfaces and I/O
| Cable length (mm) | 500 |
|---|
Light
| Emitting area (mm) | 43x35 |
|---|---|
| Colours | Red, Green, Blue, White |
Electrical
| Voltage (V) | 24 |
|---|---|
| Power R (W) | 2.5 |
| Power W/B/G (W) | 2.5 |
Mechanical
| Outer size L x W x H (mm) | 57x49x19 |
|---|---|
| Thickness (mm) | 19 |
| Mounting | 4-M3 depth 5 on back; M3 nut slot in side profile |
| Shipping weight (estimated) | 0.25 kg |
Photo shows a representative model of this series; see the specifications for this model.
Mounting and drawing data
drawing table (LS-BCP-AXB): C=42, D=18 (4-M3 depth-5 mounting hole spacing)
