Handheld code readers
Hikrobot HK-EJH70/05S/U Rugged industrial wired handheld code reader
Model HK-EJH70/05S/UHikrobot
- Resolution1280 × 800
- SensorCMOS
- InterfaceUSB
- ConnectionWired
$239.00
Ships in 2-3 weeks
0.74 kg shipping weight
Not available in the United States. Available for delivery to other countries.
Hikrobot HK-EJH70/05S/U Rugged industrial wired handheld code reader. In-house high-performance barcode algorithm efficiently reads 1D and 2D codes in industrial applications at standard distances Robust algorithm handles dirty, damaged and low-contrast codes
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | HK-EJH70/05S/U |
|---|---|
| Brand | Hikrobot |
| Min. accuracy | 3 mil |
| Detection angle | Tilt angle ± 60°, skew angle ± 60°, rotation angle 360° |
| Symbol contrast | 20 % |
| Laser safety class | Laser 2 |
Optics
| Depth of field | Code 39(3 mil):15 mm ~ 60 mm; Code 39(5 mil):5 mm ~ 80 mm; Data Matrix(5 mil):10 mm ~ 70 mm; Data Matrix(10 mil):0 mm ~ 110 mm; QR Code(5 mil):10 mm ~ 70 mm |
|---|---|
| Field of view | 31° (H) × 20° (V) |
Sensor and imaging
| Symbologies | 1D code: Code 39, Code 93, Code 128, GS1- Code 128, ITF 25, Coda Bar, EAN8, EAN13, ISBN, ISSN, ITF14, UPCA, UPCE; Matrix 2D code: QR Code, Data Matrix, Micro QR, Aztec, Han Xin; Stacked 2D code: PDF417 |
|---|---|
| Sensor type | CMOS |
| Resolution | 1280 × 800 |
| Aiming system | Cross laser aiming |
Interfaces and I/O
| Communication protocol | GigE: SmartSDK, TCP Client, TCP Server, FTP, Profinet, EthernetIP, Modbus, UDP, Serial, FINS, Melsec/SLMP; USB port: SmartSDK, USB (HID/CDC), Serial |
|---|---|
| Data interface | Ethernet: Fast Ethernet (100 Mbit/s), RS-232, DC terminal; USB: USB 2.0, DC terminal, RS-232 |
| Client software | IDMVS |
Light
| Ambient illumination | 0 ~ 100000 lux |
|---|---|
| Light source | 2 light types supported: diffuse light (red), direct light (white) |
| Wavelength | 650 nm |
Environment and compliance
| Ingress protection | IP65 |
|---|---|
| Temperature | Working temperature: –10 °C to 50 °C (14 °F to 122 °F); Storage temperature: –20 °C to 60 °C (–4 °F to 140 °F) |
| Humidity | 20% RH to 95% RH (no condensation) |
| Certification | CE, KC |
Electrical
| Power supply | GigE: 12 VDC; USB port: USB 2.0: 5 VDC; DC terminal: 12 VDC |
|---|---|
| Current consumption | USB 2.0: 0.9 A (max. current); 0.5 A (typical current); DC terminal: 0.5 A (max. current); 0.28 A (typical current) |
| Maximum power | 1 mW |
Mechanical
| Dimension | 73.4 mm × 104 mm × 229.5 mm |
|---|---|
| Weight | Approx. 460 g |
| Drop height | 2.0 m |
| Pulse width | 8 ms |
| Shipping weight (estimated) | 0.74 kg |
