LWIR thermal camera module (LS-LM), 0.3 MP, USB3 (LS-MLM640100)
Model LS-MLM640100
Long-wave infrared thermal imaging camera module features a 640x512 resolution infrared detector, equipped with a high-performance 9.1mm anti-environmental interference lens and image processing algorithms tailored for specific scenarios.
Features
- High sensitivity, clear and stable imaging quality.
- High frame rate, fast moving target detection smooth.
- Highly integrated, convenient for secondary development.
- Small size, light weight, low power consumption.
- Multiple lens options, easy to deal with various scenarios.
Specifications
| Model | LS-MLM640100 |
|---|---|
| Reeolution | 640×512 |
| Pixth pitch | 12dia. m |
| Len | 100mm Motorized focus lens |
| Detector type | Uncooled infrared module |
| Video output interface | Optional interface: CVBS/USB(UVC)/ BT656/Bt.1120 [Support customization] |
| Resolution ratio | 640x512 |
| Response band | 8~14μm(LWIR) |
| Detector type (product page) | Vanadium Oxide |
| Pixel spacing | 12μm |
| NETD | ≤50mK |
| Lens | 100mm |
| Frame Rate | Main stream:1fps~25fps Sub stream:1fps~25fps |
| Brightness, contrast | Automatic/manual |
| Polarity | White hot, black hot |
| Color palettes | White heat,black heat,iron red,reverse iron red,rainbow,lava,feather red, spring feather red,amber,iron ash,blue black,blue red,multicolored,RGB reverse color |
| Magnification | X1X2X4 |
| Picture processing | Non-uniformity correction, digital filtering noise reduction, digital detail enhancement |
| Image mirroring | Left and right/up and down |
| Output resolution | 640x512 |
| Power protection | Overcurrent protection, overvoltage protection, reverse input protection suppress high voltage surge |
| Power supply | DC12V |
| Typical power consumption | ≤2.5W |
| Video output | RJ45 |
| Communication Interface | RS-485 |
| Size | 45*45mm(camera module)+dia. 133×118mm(100mm/1.0 motorized focus lens) |
| Weight | 216g(camera module)+870g(100mm/1.0 motorized focus lens) |
| Operating temperature | 30℃~+60℃ |
| Environment temperature | 50℃~+70℃ |
| Humidity | ≤90%RH(no condensation) |
| Temperature measurement range | 140℃~600℃ |
| Accuracy | ±2℃ or 2% of the reading |
| Sensor | Uncooled infrared module |
| Pixel size (um) | 12 |
| Voltage | DC12V |
Complete the station
The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.
Configure a system Selection guideOther sizes in the LWIR thermal camera module (LS-LM) series
| Model | Size | Power | Price | Availability | |
|---|---|---|---|---|---|
| LS-LM64046 | USB3 | $3,999.00 | 4 in stock | View | |
| LS-LM64066 | USB3 | $3,999.00 | 2 in stock | View | |
| LS-LM64091 | 0.3 MP, USB3 | 1 W | $3,999.00 | 2 in stock | View |
| LS-LM64013 | USB3 | $3,999.00 | 2 in stock | View | |
| LS-LM64015 | USB3 | $3,999.00 | 2 in stock | View | |
| LS-LM64019 | USB3 | $3,999.00 | 4 in stock | View | |
| LS-LM64025 | USB3 | $3,999.00 | 5 in stock | View | |
| LS-LM64035 | USB3 | $3,999.00 | 4 in stock | View | |
| LS-LM64050 | USB3 | $3,999.00 | 3 in stock | View | |
| LS-LM38491 | USB3 | $3,999.00 | 3 in stock | View |
