Line scan lens (LS-LS), 80 mm (LS-LS8016K)
Model LS-LS8016K
Manual focus 4K line scan lens is suitable for professional machine vision imaging,inspection of ultra-long/large size workpieces and other defect detection.
Features
- Focal length 35mm.
- Large image plane:Image circle 28mm.
- High resolution, Low magnification, Excellent imaging effect.
- Anti-shock focusing fastening method.
Specifications
| Model | LS-LS8016K |
|---|---|
| Focal Length | 80mm |
| Resolution | 16K5μ |
| F/NO | 4 ~ 16 |
| Image Circle | 80mm |
| Magnification | 0.04x0.33x |
| WD | 303.3-2071.9mm |
| Mount | M42/M58/M72/M90/F |
| Type | Line Scan Lens |
| F/NO (product page) | F4~F16 |
| Magnification (product page) | 0.04x-0.33x |
| Working Distance | 303.3mm-2071.9mm |
| Temperature range | —20℃~+60℃ |
| Distortion(%) | <0.1 |
| Relative lllumination(%) | >60 |
| Aperture | 4 ~ 16 |
| Shipping weight | 0.94 kg |
