Strobe line light controller, Total output power 1000W/48V, 4 channels (CH1/2 dual connector, CH3/4 single connector) (LS-LELS-1000-4TS-PY)
Model LS-LELS-1000-4TS-PY
Strobe line light controller, Total output power 1000W/48V, 4 channels (CH1/2 dual connector, CH3/4 single connector), Up to 10A per channel, 19M-6G connector (fits lights with 19M-6H connector), 4 external trigger inputs (RS422 differential), With GigE port, Max. frequency 100 kHz, For time-division cameras. 3 light control methods: front panel, RS-232 serial and RJ45 Ethernet External trigger port lights the light only when needed, extending its life
Features
- 3 light control methods: front panel, RS-232 serial and RJ45 Ethernet
- External trigger port lights the light only when needed, extending its life
- Power-loss memory, short-circuit protection and overload protection
- 2 drive modes, constant voltage and constant current, for more stable light output
- Automatically detects the rated current of the light to drive lights of different specifications
Specifications
| Model | LS-LELS-1000-4TS-PY |
|---|---|
| Drive mode | Constant voltage |
| Lighting mode | Pulsed |
| PWM frequency | Not supported |
| Strobe overdrive | Supported |
| Channel | 4 |
| Dimming mode | Illumination pulse width |
| Brightness level | Not supported |
| Lighting response time | < 1 us |
| Trigger mode | External trigger and internal trigger |
| Communication protocol | GigE |
| Applicable product | High-power light, Line light |
| Input voltage | 48 VDC |
| Input current | 7.5 A |
| Output current | 40 A max |
| Output power | 1000 W max |
| Output current for each channel | 10 A max |
| Trigger in | Level signal DC 5 to 24 V / 6 mA |
| Trigger out | Not supported |
| Power supply interface | AC socket |
| Console interface | GigE |
| Digital I/O | 3× RS-422 |
| Lighting output connector | 4 × 19M-6G |
| Dimension | 323 mm × 72 mm × 200 mm |
| Shell material | Galvanized steel sheet |
| Weight | Approx. 3500 g |
| Temperature | Working temperature: 0 °C to 40 °C (32 °F to 104 °F); Storage temperature: –20 °C to 60 °C (–4 °F to 140 °F) |
| Humidity | 20% RH to 85% RH (no condensation) |
| Ingress protection | IP50 (when properly installed) |
| Cooling mode | Forced cooling (built-in fan) |
| Certification | CE, RoHS |
| Shipping weight (estimated) | 5.00 kg |
